Description
| Name | KCD1 Rocker Switch |
| Contact Resistance | ≤50mΩ |
| Insulation Resistance | ≥1000MΩ |
| Dielectric Strength | 1500V AC, 1min |
| Operating Temperature | T55,T85,T125 |
| Electronic Life(cycles) | 10000 |
| Max.Rating Current&Voltage | |
 |
16(4)A 250V AC T85 |
 |
16R(4)A 125V AC 16R(4) 250V AC 1HP 125VAC |
 |
14(4)A 250V AC T125, 10(4)A 250V AC T125 16(4)A 250V AC T85, 16A 250V AC |
Why Choose Our KCD1 Rocker Switch?
Our KCD1 Rocker Switch stands out for its durability, efficiency, and customizability. With a maximum rating of 16A at 250V AC, it can handle heavy electrical loads, making it ideal for a wide range of applications. The LED indicator adds convenience, allowing you to easily see the switch's status. Plus, as a factory supplier, we offer wholesale pricing, making it a cost-effective choice for bulk orders.
What Are the Key Features of Our KCD1 Rocker Switch?
The KCD1 Rocker Switch features low contact resistance (≤50mΩ) and high insulation resistance (≥1000MΩ), ensuring safe and reliable operation. It also meets strict dielectric strength standards (1500V AC, 1min) and can operate effectively across a wide temperature range (T55, T85, T125). Additionally, it supports both SPST and SPDT configurations, providing flexibility for your switching needs.
Can We Customize the KCD1 Rocker Switch?
Yes! As a factory supplier, we have the capability to customize the KCD1 Rocker Switch to meet your specific requirements. Whether you need a different color, size, or configuration, we can work with you to create a switch that perfectly fits your application. Just order in sufficient quantities, and we'll take care of the rest.
