KCD2 250VAC 16A Rocker Switch | Wholesale Factory Supplier

Category: Tags: , , , ,
>= 100  pieces
$0.50
0 reviews

Wholesale KCD2 Rocker Switch | Factory Supplier | Durable & Reliable

Description

Introducing our high-quality KCD2 Rocker Switch, a reliable choice for various applications. As a factory supplier offering wholesale deals, we ensure top-notch products at competitive prices. This switch boasts a max current of 16A and max voltage of 250VAC, with a mechanical life of 100,000 cycles and an electrical life of 10,000 cycles, outperforming many competitors. Made of durable plastic, it comes in 4P pins and is available in multiple colors including Red, Yellow, Green, Black, White, Blue, Gray, and Orange. It’s certified by CQC, CE, ENEC, UL, CB, and ROHS, guaranteeing safety and quality. With an IP40 rating, it’s suitable for industrial, automotive, marine, bus, and off-road vehicle applications. Our switch stands out with its high dielectric strength of 1500V AC 1min and low contact resistance of ≤50mΩ. Choose us for factory-direct pricing, excellent customer service, and reliable after-sales support.
contact resistance
≤50MΩ
electronic life
10000
insulation resistance
≥1000MΩ
operating temperature
T25 T85 T125
dielectric strength
1500V
IP code
IP40

Electronic component for cross-border e-commerce


Key Features

Our KCD2 Rocker Switch offers a max current of 16A and max voltage of 250VAC, making it suitable for a wide range of applications. With a mechanical life of 100,000 cycles and an electrical life of 10,000 cycles, it ensures long-lasting performance.

Durable Construction

Made of high-quality plastic, this switch is built to withstand harsh conditions. It comes in multiple colors to suit different design needs and is certified by multiple international standards, ensuring safety and reliability.

Why Choose Us?

As a factory supplier, we offer wholesale pricing and excellent customer service. Our switch stands out with its high dielectric strength and low contact resistance, providing superior performance compared to competitors. Choose us for reliable after-sales support and a product that meets your needs.

Push Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch Customized

Additional information

Max. Current

16A
Max. Voltage

250V
Place of Origin

Shanghai, China
Brand Name

Yongxing
Model Number

KCD2-21-C
Application

Industrial, Cars, MARINE, BUSES, electric equipment, off-road vehicles
Material

plastic
Pins

4P
Whether the smart

NO
Mechanical Life

100,000 cycles
IP level

IP40
Switch Action

ON-OFF
Termination Type

solder
Color

Red, Yellow ,Green, Black, White, Blue, Gray, Orange
Certificate

CQC, CE, ENEC,UL, CB, ROHS
Current

16A
Operating temperature

T55,T85,T125
Electrical life

10,000
Dielectric Strength

1500V AC 1min
Contact Resistance

≤50mΩ
Function

DPST DPDT
