Description
Product Specifications:
– Contact Resistance: ≤50mΩ
– Insulation Resistance: ≥1,000MΩ
– Dielectric Resistance: 1,500V AC, 1 min
– Electrical Life: 10,000 cycles
– Mechanical Life: 50,000-100,000 cycles
– Max. Rating Current & Voltage: 6A 250V AC
– Certifications: CQC, CE, UL, CB, ENEC, ROHS
– IP Level: IP41, IP65
– Housing Color: Black
– LED Color Options: Amber, Orange-Red, Blue, Green
Product Advantages:
Our rocker switch stands out with its durability, high electrical performance, and wide range of certifications, ensuring safety and reliability. The customizable LED color options add a touch of personalization to your projects.
Applications:
Ideal for electric fireplaces, home appliances, industrial equipment, and more. Its robust design and excellent performance make it a preferred choice for various applications.
After-Sales Service:
We provide comprehensive after-sales service, including technical support and warranty, ensuring your satisfaction with our products.
Choose us as your trusted factory supplier and wholesaler for all your electrical component needs.
| Contact Resistance | ≤50mΩ rocker switches for electric fireplace |
| Insulation Resistance | ≥1,000MΩ |
| Dielectric Resistance | 1,500V AC , 1 min |
| Electronic life(cycles) | 10,000 cycles 4 pin on-off rocker switch |
| Operating Temperature | T55 rocker switch |
| Certification |
CQC , CE |
| Max. Rating Current & Voltage (CQC , CE) |
6A 250V AC |
Why Choose Our KCD8 3-Pin Black Rocker Switch?
Our KCD8 3-Pin Black Rocker Switch offers superior durability, high electrical performance, and a wide range of certifications, ensuring safety and reliability for your projects. With customizable LED color options, it adds a personalized touch to your applications.
What Are the Key Specifications of Our Rocker Switch?
Our rocker switch features a contact resistance of ≤50mΩ, insulation resistance of ≥1,000MΩ, dielectric resistance of 1,500V AC for 1 minute, and an electrical life of 10,000 cycles. It is rated for 6A 250V AC and comes with certifications including CQC, CE, UL, CB, ENEC, and ROHS.
What Are the Applications of Our Rocker Switch?
Our KCD8 3-Pin Black Rocker Switch is ideal for electric fireplaces, home appliances, industrial equipment, and more. Its robust design and excellent performance make it a versatile choice for various applications.
