KD2 12V 8-Pin 2NO 2NC Illuminated Push Button Switch | Factory Wholesale

Category: Tags: , , , ,
>= 50  pieces
$0.72
0 reviews

KD2 12V Push Button Switch | Factory Wholesale | Supplier

Clean All

Description

Introducing our KD2 12V 8-Pin 2NO 2NC Illuminated Push Button Switch, a high-quality product from our factory. This switch is designed with precision and durability in mind, featuring a square head and pin terminals for easy installation. It operates at a maximum current of 3A and a maximum voltage of 250V, making it suitable for a wide range of applications including electric, home appliances, and industrial control systems. The switch is self-locking with an electronic and mechanical structure, ensuring reliable performance. It comes with a red dot illuminated LED, operating at 12V AC/DC, and has an IP40 rating for dust protection. Our switch stands out with its long electrical life of 10,000 cycles and a wide operating temperature range from -25°C to +55°C. As a factory supplier, we offer wholesale prices and excellent after-sales service. Choose our switch for its superior quality, competitive pricing, and reliable performance.
contact resistance
≤50MΩ
electronic life
10000
insulation resistance
≥100MΩ
operating temperature
25T55
dielectric strength
1500V
IP code
IP40

Electronic component product image for cross-border e-commerceElectronic device product display for e-commerce website


Key Features

Our KD2 12V 8-Pin 2NO 2NC Illuminated Push Button Switch is designed for versatility and reliability. With a self-locking mechanism and a long electrical life of 10,000 cycles, it ensures consistent performance over time. The red dot illuminated LED provides clear visual indication, making it ideal for applications where visibility is crucial.

Superior Quality

As a factory supplier, we prioritize quality control. Our switch is made from durable plastic and features an electronic and mechanical structure for enhanced reliability. It meets CQC, CE, and ROHS certifications, ensuring safety and compliance with international standards.

Why Choose Us?

Choose our switch for its competitive pricing, excellent after-sales service, and the assurance of dealing directly with a factory supplier. We offer wholesale prices and can accommodate large orders, making us the ideal partner for your business needs.

Push Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch Customized

Additional information

Max. Current

3A
Max. Voltage

250V
Place of Origin

Shanghai, China
Brand Name

Yongxing
Model Number

KD2-A21L12-BG-R
LED

Other
Application

Electric, Home Appliance, Industrial Control, latching
Material

plastic
Structure

Electronic, Mechanical, Electromagnetic
Head Type

Square Head
Terminal Type

Pin terminal
Whether the smart

NO
illuminated Type

dot illuminated
IP level

IP40
Switch Combination

1NO1NC, 1NO, 2NO2NC
Certificate

CQC CE ROHS
Operation type

Self-locking
Function

2NO 2NC
LED color

Red
Light voltage

12V AC/DC
Electrical Life

10,000 cycles
Mounting Hole Size

17x17mm
Operating temperature

-25-+55
Certification

CQC
