RS1 6A 250V 8-Position Rotary Switch – Wholesale from Factory

Category: Tags: , ,
500 - 900  pieces
$0.50

>= 1,000  pieces
$0.30
0 reviews

Wholesale RS1 6A 250V 8-position rotary switches from factory supplier.

Description

Introducing our RS1 6A 250V 8-position rotary switch, perfect for home appliances. As a direct factory supplier, we offer wholesale pricing on high-quality switches tailored to your needs. Our switch features a maximum rating of 6A 250VAC, a contact resistance of less than 50mΩ, and an insulation resistance greater than 100mΩ. With a dielectric resistance of 1500V and an electronic life of 10,000 cycles, it’s built to last. The operating temperature is T125, and it comes with CQC and ENEC certifications. Our factory, equipped with independent plants, injection workshops, and advanced experimental equipment, ensures top-notch quality. With over 60 senior engineers and 5S/5m management standards in all workshops, we guarantee excellence. Customize your switch with us for large quantities, and enjoy our factory-direct pricing and reliable after-sales service.
max.rating cnrrent&voltage
6a 250vac
contact resistance
<50mΩ
insulation resistance
>100mΩ
dielectrice resistance
1500V
electronic life
10000
operating temperature
T125
CQC,ENEC

Electronic component image for cross-border e-commerceElectronic device image for e-commerce optimizationElectronic part image for SEO optimization


Why Choose Our RS1 Rotary Switch?

Our RS1 rotary switch stands out with its high-quality construction, featuring a 6A 250V rating, low contact resistance, and excellent insulation properties. Designed for long electronic life and reliability, it's perfect for home appliances and electrical controls. As a factory supplier, we offer customization options for large quantities and competitive wholesale pricing.

What Are the Key Specifications?

The RS1 switch has 8 positions, a T125 operating temperature, and IP41 protection level. It's single-pole and comes with CQC and ENEC certifications, ensuring safety and compliance. The switch's mechanical life is 100,000 cycles, and it has a dielectric resistance of 1500V.

How Can We Benefit Your Business?

By choosing us as your supplier, you get access to factory-direct pricing, reliable after-sales service, and the flexibility to customize switches to meet your specific requirements. Our advanced facilities and experienced engineers ensure top-notch quality and fast delivery times, helping you stay ahead in the market.

Push Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch Customized

Additional information

Whether the smart

NO
Max. Current

6A
Max. Voltage

250V AC
Place of Origin

Shanghai, China
Brand Name

Yongxing
Model Number

RS1
Mechanical Life

100000
IP level

IP41
name

6a 250v 4-way selector switch
Certification

CCC,CQC, CE, RoHS,
Contact Resistance

≤50mΩ
Insulation resistance

≥100mΩ
dielectric resistance

1500V
operating temperature

T125
Color

Black
number of poles

Single-pole
Electronic life

10000cycles
Position

1~8 Positions
