Description
Shanghai Factory Direct KCD8 3-Pin Illuminated Rocker Switch
As a leading supplier and factory, we offer high-quality KCD8 3-pin illuminated rocker switches. These switches are designed with precision and durability in mind, making them ideal for a wide range of applications.
Product Specifications
- Brand Name: SK (Shangkai)
- Model Number: KCD8
- Max. Current: 6A
- Max. Voltage: 250V AC
- Pins: 2-pin/3-pin
- Contact Resistance: ≤50mΩ
- Insulation Resistance: ≥1,000MΩ
- Dielectric Resistance: 1,500V AC, 1 min
- Electrical Life: 10,000 cycles
- Mechanical Life: 50,000-100,000 cycles
- IP Level: IP41
- Housing Color: Black
- LED Color: Amber, Orange, Red, Blue, Green
- Certificates: UL, CE, CQC, CB, ENEC, ROHS
Product Advantages
Our KCD8 3-pin illuminated rocker switches stand out from the competition with their superior quality, long electrical life, and wide range of LED color options. They are perfect for use in electric fireplaces, industrial equipment, and more. As a factory direct supplier, we offer competitive wholesale prices and excellent customer service.
After-Sales Service
We provide a comprehensive after-sales service, including product warranties and technical support. Our team is always ready to assist you with any questions or concerns you may have.
| Contact Resistance | ≤50mΩ rocker switches for electric fireplace |
| Insulation Resistance | ≥1,000MΩ |
| Dielectric Resistance | 1,500V AC , 1 min |
| Electronic life(cycles) | 10,000 cycles 4 pin on-off rocker switch |
| Operating Temperature | T55 rocker switch |
| Certification |
CQC , CE |
| Max. Rating Current & Voltage (CQC , CE) |
6A 250V AC |
Why Choose Our KCD8 3-Pin Illuminated Rocker Switch?
Our KCD8 3-pin illuminated rocker switch is designed to meet the highest standards of quality and performance. With its long electrical life, multiple LED color options, and durable black housing, it is perfect for use in a wide range of applications, including electric fireplaces and industrial equipment.
What Are the Key Features of Our Switch?
Our switch features a contact resistance of ≤50mΩ, an insulation resistance of ≥1,000MΩ, and a dielectric resistance of 1,500V AC for 1 minute. It also has an electrical life of 10,000 cycles and a mechanical life of 50,000-100,000 cycles, ensuring long-lasting reliability.
How Can We Help You?
As a factory direct supplier, we offer competitive wholesale prices and excellent customer service. Whether you need a single switch or a large quantity, we are here to meet your needs. Contact us today to learn more about our KCD8 3-pin illuminated rocker switch and how it can benefit your business.
