Description
Specifications:
- Model Number: AX16-212-3
- Protection Level: IP40
- Max. Current: 3A
- Max. Voltage: 250V AC
- Contact Resistance: ≤50mΩ
- Insulation Resistence: ≥100MΩ
- Dielectric Strength: 1500V
- Operating Temperature: 25°C to 55°C
- Electrical Life: 25,000 cycles
- Mechanical Life: 50,000 cycles
- Panel Cut-out: 16mm
- Panel Thickness: 0.5-6.0mm
- Position: 3 Positions, 2NO+2NC
- Color: Blue
Advantages:
- High-quality materials ensure long-lasting performance.
- IP40 protection level provides excellent dust resistance.
- Competitive pricing as a direct factory supplier.
- Suitable for a wide range of applications.
After-sales Service:
We offer comprehensive after-sales service, including technical support and warranty coverage, to ensure your satisfaction with our product.
|
item
|
value
|
|
Place of Origin
|
Shanghai,China
|
|
Brand Name
|
SK(Shangkai)
|
|
Model Number
|
AX16-212-3
|
|
Protection Level
|
IP40
|
|
Max. Current
|
3A
|
|
Max. Voltage
|
250V AC
|
|
Contact Resistance
|
≤50mΩ
|
|
Insulation Resistence
|
≥100MΩ
|
|
Dielectric Strength
|
1500V
|
|
Operating Temperature
|
25T55
|
|
Electrical Life
|
25000
|
|
Mechanical Life
|
50000
|
|
Panel cut out
|
16mm
|
|
Panel thickness
|
0.5-6.0mm
|
|
Position
|
3 Positions,2NO+2NC
|
Why Choose Our 16mm IP40 Rotary Switch?
Our 16mm IP40 Rotary Switch stands out for its durability, reliability, and dust-resistant design. With an IP40 protection level, it ensures excellent performance in environments where dust is a concern. The self-locking mechanism adds an extra layer of safety, making it ideal for various applications.
Key Features and Benefits
This rotary switch offers a high maximum current and voltage rating, ensuring it can handle demanding electrical loads. Its long electrical and mechanical life means fewer replacements and lower maintenance costs over time. As a factory supplier, we can offer competitive pricing without sacrificing quality.
Applications and Suitability
Our 16mm IP40 Rotary Switch is suitable for a wide range of applications, including electrical control systems, industrial equipment, and home appliances. Its compact size and robust design make it a versatile choice for various industries.
