Description
Our rocker switch boasts a mechanical life of 50,000 cycles and an electronic life of 10,000 cycles, ensuring long-lasting performance. It features a contact resistance of ≤50mΩ and an insulation resistance of ≥1000MΩ, providing excellent electrical properties. The dielectric strength of 1500VAC for 1 minute guarantees safety and reliability.
What sets our switch apart is its compact dimension code of A1 (21.7x15x15.8, 19.1x13x13) and a contact piece code of H (7.5 length, 2.2×0.6 welding type), making it easy to install and integrate into your marine electrical systems. Additionally, it is available in a range of colors including red, yellow, green, black, blue, orange, white, and gray, allowing you to match it with your boat’s interior.
As a trusted supplier, we offer competitive wholesale pricing and excellent customer service. Our switches are UL and ROHS certified, ensuring compliance with international safety standards. Choose our UL Certified Boat Rocker Switch for a reliable and cost-effective solution for your marine electrical needs.
|
item
|
value
|
|
Place of Origin
|
Shanghai, China
|
|
Brand Name
|
SK(shangkai) Yongxing
|
|
Model Number
|
KCD3-11-CA1H-W-S-01
|
|
Max. Current
|
15R(3)
|
|
Max. Voltage
|
125V AC
|
|
Mechanical Life
|
50000 Cycles
|
|
Contact Resistance
|
≤50mΩ
|
|
Insulation Resistance
|
≥1000MΩ
|
|
Dielectric Strength
|
1500VAC 1 Minute
|
|
Electronic Life (cycles)
|
10,000
|
|
Certificate
|
UL ROHS
|
|
Circuit
|
SPST
|
|
Dimension Code
|
A1 (21.7x15x15.8 , 19.1x13x13)
|
|
Contact Piece Code
|
H (7.5 length, 2.2×0.6 welding type)
|
|
Color
|
Red,Yellow,Green,Black,Blue,Orange,White,Gray
|
|
Function
|
On Off
|
Why Choose Our UL Certified Boat Rocker Switch?
Our UL Certified Boat Rocker Switch is designed specifically for marine applications, offering reliable and durable performance. With a maximum current of 15R(3) and a maximum voltage of 125V AC, it is perfect for controlling on/off functions in boats and other marine environments. The switch's compact dimension and easy-to-install design make it a convenient choice for your marine electrical systems.
What Are the Key Features of Our Rocker Switch?
Our rocker switch boasts a mechanical life of 50,000 cycles and an electronic life of 10,000 cycles, ensuring long-lasting performance. It features excellent electrical properties with a contact resistance of ≤50mΩ and an insulation resistance of ≥1000MΩ. The dielectric strength of 1500VAC for 1 minute guarantees safety and reliability. Additionally, it is available in a range of colors to match your boat's interior.
Why Buy from Us as a Supplier?
As a direct factory supplier, we offer competitive wholesale pricing on our UL Certified Boat Rocker Switch. Our switches are UL and ROHS certified, ensuring compliance with international safety standards. We pride ourselves on providing excellent customer service and fast shipping, making us a trusted choice for your marine electrical needs.
