Factory-direct Waterproof 4-Pin Push Button Switch. Wholesale supplier. High quality, customizable.

Description

Introducing our premium Waterproof 4-Pin Push Button Switch, a top-notch product from our factory. As a direct supplier, we offer wholesale prices for bulk purchases. Our switch is designed with a max rating of 3A at 250VAC, ensuring reliable performance. With an IP65 rating, it provides excellent waterproof protection, making it ideal for outdoor and harsh environments. The switch features a low contact resistance of <50mΩ and high insulation resistance of >100mΩ, ensuring efficient and safe operation. It has a long electrical life of at least 10,000 cycles, reducing the need for frequent replacements. Our switch operates within a wide temperature range of -25°C to +85°C, making it suitable for various applications. We have an independent plant, injection workshop, and advanced experimental equipment, with over 60 senior engineers ensuring high-quality production. All workshops adhere to 5S and 5m management standards. We offer customization services for large quantities to meet your specific requirements. Choose us for factory-direct prices, reliable quality, and excellent customer service.
max.rating cnrrent&voltage
3a 250vac
contact resistance
<50mΩ
insulation resistance
>100mΩ
dielectrice resistance
1500V
electronic life
10000
operating temperature
-25℃~+85℃

Electronic component image for cross-border e-commerceElectronic device product image for e-commerceElectronic gadget product display for e-commerceElectronic part product image for cross-border sales


Why Choose Our Waterproof 4-Pin Push Button Switch?

Our switch stands out with its IP65 waterproof rating, ensuring durability in harsh environments. With a max rating of 3A at 250VAC and a long electrical life of at least 10,000 cycles, it offers reliable performance and reduces maintenance costs. As a factory supplier, we provide wholesale prices and customization options for bulk orders.

What Are the Key Features of Our Switch?

Key features include a low contact resistance of <50mΩ, high insulation resistance of >100mΩ, and a wide operating temperature range of -25°C to +85°C. These features ensure efficient and safe operation in various applications.

How Can We Help You?

We offer factory-direct prices, reliable quality, and excellent customer service. With over 60 senior engineers and advanced production facilities, we can customize the switch to meet your specific requirements. Contact us today for wholesale pricing and customization options.

Push Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch Customized

Additional information

Max. Current

3A

Max. Voltage

250V

Place of Origin

China

Brand Name

SK

Model Number

KA7

LED

NO

Function

SPST ON OFF

Electrical Life

Min 10000 Cycles

IP Rating

IP65

Certification

CQC CE
