Description
Our switch features a compact design with a black plastic casing, ensuring both aesthetics and protection. It boasts an IP40 rating, providing resistance against dust and water ingress, making it ideal for use in various environments. The switch operates with a SPDT circuit, offering versatile connectivity options.
Technical specifications include a maximum current rating of 3(3)A and a maximum voltage of 250V AC, ensuring compatibility with a broad range of electrical systems. With a mechanical life of 100,000 times and an electronic life of 50,000 cycles, our switch guarantees long-lasting performance.
The contact resistance is ≤50MΩ, and the insulation resistance is ≥100MΩ, ensuring safe and efficient operation. The operating temperature range is from -25℃ to 125℃, making it suitable for both extreme cold and hot conditions.
Our Waterproof Micro Limit Switch is perfect for industrial, electric power, household, and telecommunication applications. Its durability, reliability, and competitive pricing make it a standout choice in the market. Trust us, the factory supplier, for all your wholesale needs.
|
contact resistance
|
≤50MΩ
|
electronic life（cycles）
|
50000
|
|
insulation resistance
|
≥100MΩ
|
operating temperature
|
25T125
|
|
dielectric strength
|
1500V
|
max.rated current & voltage
|
3(3)A 250V AC
|
Why Choose Our Waterproof Micro Limit Switch?
Our Waterproof Micro Limit Switch stands out due to its robust construction, waterproof design, and long mechanical life. With an IP40 rating, it offers reliable protection against dust and water, making it suitable for various environments. The SPDT circuit provides versatile connectivity, while the high current and voltage ratings ensure compatibility with a wide range of electrical systems.
What Are the Key Features?
Key features include a compact black plastic casing, a maximum current rating of 3(3)A, a maximum voltage of 250V AC, and a mechanical life of 100,000 times. The switch also boasts an electronic life of 50,000 cycles, ensuring long-lasting performance. With a contact resistance of ≤50MΩ and an insulation resistance of ≥100MΩ, it guarantees safe and efficient operation.
Where Can It Be Used?
Our Waterproof Micro Limit Switch is perfect for industrial, electric power, household, and telecommunication applications. Its durability and reliability make it an ideal choice for any system requiring a reliable and long-lasting switch. As a factory supplier, we offer wholesale pricing, making it a cost-effective solution for all your needs.
