Wholesale 10A 24V T55 Rocker Switch | Factory Direct Supply

Name: Wholesale 10A 24V T55 Rocker Switch | Factory Direct Supply
SKU: 56407
Availability: InStock

Category: KCD1 series Rocker Switch Tags: factory Direct, Rocker Switch, Supplier, T55 Switch, Wholesale Switch

>= 1,000 pieces
$0.35

Rated 0 out of 5

0 reviews

Wholesale 10A 24V T55 Rocker Switch | Factory Direct Supplier

Description
Specification

Description

Introducing our high-quality 10A 24V T55 Rocker Switch, a versatile and reliable component designed for a wide range of electrical applications. As a factory direct supplier, we offer competitive wholesale prices and ensure top-notch quality. This rocker switch boasts a contact resistance of ≤50mΩ, insulation resistance of ≥1000MΩ, and dielectric strength of 1500V AC for 1 minute, ensuring safety and durability. With a mechanical life exceeding 10,000 cycles, it guarantees long-lasting performance. Our switch is available in various models, including KCD1, KCD2, KCD3, and more, each with specific voltage and current ratings to suit your needs. Choose from a range of actuator and housing colors to match your design. Ideal for use in automotive, industrial, and home appliances, our rocker switch stands out with its superior quality and affordability. As a trusted supplier, we provide excellent after-sales service and support. Don’t miss out on this factory-direct deal!

SPECIFICATION
	contact resistance	≤50mΩ
	insulation resistance	≥1000MΩ
	dielectric strength	1500V AC,1min
	electronic life(cycles)	10000
KCD1	operating temperature	Max.Rating Current&Voltage	Reference price
	T55,T85,T125	16(4)A 250V AC T85	$0.186~0.721
		16R(4)A 125V AC
		16R(4)A 250V AC
		1HP 125V AC
		16(4)A 250V AC T125
		10(4)A 250V AC T125
		16A 250V AC
KCD2	T55,T85,T125	16(4)A 250V AC T85	$0.249~1.077
		16R(4)A 125V AC
		16R(4)A 250V AC
		1HP 125V AC
		16(4)A 250V AC T125
		10(4)A 250V AC T125
		16A 250V AC
KCD3	T55,T105	10(3)A 250V AC T85	$0.121~0.622
		6(3)A 250V AC T85
		15R(3) 125V AC
		10R(3) 250V AC
		1/3HP 125V AC
		10(3)A 250V AC T105
		6(3)A 250V AC T105
		6A 250V AC
		4A 250V AC T105
KCD5	T55	6A 250V AC	$0.245~0.475
		15R(3) 125V AC
		10R(3) 250V AC
		1/3HP 125V AC
KCD6	T55	6A 250V AC	$0.252~0.549
KCD7	T55	6A 250V AC	$0.157~0.393
KCD8	T55,T85,T105	6A 250V AC	$0.157~0.536
		10(3)A 250V AC T105
		6(3)A 250V AC T105
		6A 250V AC
		4A 250V AC T105
KCD10	T55,T85,T105	2A 250V AC	$0.088~0.131

KCD11	Function	3 files
	Mechanical Life(cycles)	>10000
	Amibent temperature	0℃~105℃
	Nomal position	2.5-7N
	Max.Rating Current&Voltage	10(1)A 250V AC T105
	Note:Single load 5(1)A 250V AC T105

SPECIFICATION
	contact resistance	≤50mΩ
	insulation resistance	≥1000MΩ
	dielectric strength	1500V AC,1min
	electronic life(cycles)	10000
KCD1	operating temperature	Max.Rating Current&Voltage	Reference price
	T55,T85,T125	16(4)A 250V AC T85	$0.186~0.721
		16R(4)A 125V AC
		16R(4)A 250V AC
		1HP 125V AC
		16(4)A 250V AC T125
		10(4)A 250V AC T125
		16A 250V AC
KCD2	T55,T85,T125	16(4)A 250V AC T85	$0.249~1.077
		16R(4)A 125V AC
		16R(4)A 250V AC
		1HP 125V AC
		16(4)A 250V AC T125
		10(4)A 250V AC T125
		16A 250V AC
KCD3	T55,T105	10(3)A 250V AC T85	$0.121~0.622
		6(3)A 250V AC T85
		15R(3) 125V AC
		10R(3) 250V AC
		1/3HP 125V AC
		10(3)A 250V AC T105
		6(3)A 250V AC T105
		6A 250V AC
		4A 250V AC T105
KCD5	T55	6A 250V AC	$0.245~0.475
		15R(3) 125V AC
		10R(3) 250V AC
		1/3HP 125V AC
KCD6	T55	6A 250V AC	$0.252~0.549
KCD7	T55	6A 250V AC	$0.157~0.393
KCD8	T55,T85,T105	6A 250V AC	$0.157~0.536
		10(3)A 250V AC T105
		6(3)A 250V AC T105
		6A 250V AC
		4A 250V AC T105
KCD10	T55,T85,T105	2A 250V AC	$0.088~0.131

KCD11	Function	3 files
	Mechanical Life(cycles)	>10000
	Amibent temperature	0℃~105℃
	Nomal position	2.5-7N
	Max.Rating Current&Voltage	10(1)A 250V AC T105
	Note:Single load 5(1)A 250V AC T105

KCD1	KCD2	KCD3	KCD5	KCD6
KCD7	KCD8	KCD10	KCD11

Key Features and Advantages

Our 10A 24V T55 Rocker Switch is engineered for reliability and durability, with a mechanical life exceeding 10,000 cycles. It offers superior contact and insulation resistance, ensuring safe and efficient operation. With multiple models available, you can find the perfect switch for your specific voltage and current requirements.

Why Choose Our Rocker Switch?

As a factory direct supplier, we offer unbeatable wholesale prices without compromising on quality. Our switches are rigorously tested to meet international standards, including CCC, CQC, CE, RoHS, and UL certifications. Choose from a variety of actuator and housing colors to match your design preferences.

Wide Range of Applications

Ideal for automotive, industrial, and home appliance applications, our rocker switch provides reliable electrical control. Its compact design and easy installation make it a popular choice among professionals and DIY enthusiasts alike. Trust in our factory-direct quality and support for all your electrical needs.

Additional information

Max. Current	16A
Max. Voltage	250V AC
Place of Origin	Shanghai, China
Brand Name	shangkai
Model Number	KCD1
Whether the smart	NO
Mechanical Life	10000 Cycles
Certification	CCC,CQC, CE, RoHS,UL
Actuator color	red green yellow blue orange black gray white
Maximum current	10A
Contact Resistance	≤50mΩ
Insulation Resistance	≥1000MΩ
DIELECTRIC STRENGTH	1500V AC,1min
Name	10A t55 24 volt wiring diagram rocker switch
Housing color	red green yellow blue orange black gray white
Rating current	16A
Voltage	AC250V/AC125V
