Description
Our switch features a durable construction with a contact resistance of ≤50mΩ and an insulation resistance of ≥1000 MΩ, ensuring reliable performance. It supports a maximum rating current of 3A and a voltage of 250V AC, making it suitable for both resistive and inductive loads. The switch is available with LED options (2V, 6V, 12V, 24V, 110V, 220V) and offers both momentary and latching actions, as well as 1NO1NC or 2NO2NC switch combinations.
With an IP40 protection level and an operating temperature range of -25℃ to +55℃, this switch is built to withstand harsh environments. It boasts an electrical life of 50,000 cycles and a mechanical life of up to 100,000 cycles, ensuring long-lasting durability. Our switch is also CQC and CE certified, guaranteeing its quality and safety.
As a factory direct supplier, we offer competitive pricing and fast delivery times. Whether you need a single unit or bulk quantities, we can meet your needs. Contact us today to learn more about our wholesale pricing and customization options.
| Max.Rating Current & Voltage(Resistive Load) | 1A/250V AC |
| Contact Resistance | ≤50mΩ |
| Insulation Resistance | ≥1000 MΩ |
| Dielectric Strength | 1500V |
| Electronic Life(cycles) | 10000 |
| Mechanical Life(cycles) | 50000 |
| Operating temperature | -25°c~+55°c |
| IP code | IP40 |
Why Choose Our LED Push Button Switch?
Our LED Push Button Switch stands out for its durability, versatility, and reliability. With a contact resistance of ≤50mΩ and an insulation resistance of ≥1000 MΩ, it ensures stable performance in various applications. The switch supports both momentary and latching actions, as well as 1NO1NC or 2NO2NC switch combinations, making it suitable for a wide range of needs.
What Are the Key Features?
Key features include a maximum rating current of 3A and a voltage of 250V AC, an IP40 protection level, and an operating temperature range of -25℃ to +55℃. The switch also offers LED options (2V, 6V, 12V, 24V, 110V, 220V) for easy status indication. With an electrical life of 50,000 cycles and a mechanical life of up to 100,000 cycles, it is built to last.
Why Buy from Us?
As a factory direct supplier in Shanghai, China, we offer competitive pricing and fast delivery times. Our switch is CQC and CE certified, guaranteeing its quality and safety. Whether you need a single unit or bulk quantities, we can meet your needs with our wholesale pricing and customization options.
