Description
Our switch boasts a robust metal construction, ensuring durability and longevity. It is CE and RoHS certified, guaranteeing safety and compliance with international standards. The switch features an impressive mechanical life of 1,000,000 cycles and an electronic life of 50,000 hours, making it a reliable choice for your projects.
Key specifications include a maximum current of 0.1A and a maximum voltage of 12VDC. The switch is also equipped with an LED indicator (available in multiple colors: Black, Blue, Green, Red, White, Yellow), providing visual feedback for operation. It operates within a temperature range of -25℃ to +65℃, making it suitable for various environments.
What sets our switch apart is its versatility and customization options. Choose from different switch combinations (1NO1NC, 1NO, 2NO2NC, 2NO) to suit your specific needs. Additionally, our factory-direct pricing ensures you get the best value for your money.
We offer comprehensive after-sales service, including technical support and warranty coverage. Trust us as your reliable supplier for all your electrical switch needs.
|
item
|
value
|
|
Certification
|
CE RoHS
|
|
Whether the smart
|
Yes
|
|
Place of Origin
|
China
|
|
Brand Name
|
Shanghai Yongxing
|
|
Model Number
|
YXDGQ10F-11
|
|
Protection Level
|
IP40
|
|
Max. Current
|
0.1A
|
|
Max. Voltage
|
12VDC
|
|
LED
|
Other
|
|
Electronic Life
|
50000 cycles
|
|
Mechanical Life
|
1000000 cycles
|
|
Working Environment Temperature
|
-25℃~+65℃
|
|
Switch circuit
|
1NO 1NC
|
|
Electrical Resistance
|
AC500V, 1min, no flicker and breakdown
|
|
Contact Resistance
|
≤50mΩ
|
|
Insulation Resistance
|
≥100MΩ
|
Why Choose Our 10mm Metal Push Button Switch?
Our 10mm metal push button switch is designed for durability and reliability, making it an ideal choice for industrial and home applications. With a mechanical life of 1,000,000 cycles and an electronic life of 50,000 hours, you can trust this switch to perform consistently over time.
What Makes Our Switch Stand Out?
Unlike other switches on the market, ours is factory-direct, ensuring you get the best price without compromising on quality. The switch is also highly customizable, with multiple switch combinations and LED colors available to suit your specific needs.
How Can I Use This Switch in My Projects?
This switch is perfect for a wide range of applications, from controlling industrial machinery to automating home systems. Its DC12V rating and 1NO1NC configuration make it versatile and easy to integrate into your existing setup.
