Description
Our LED Push Button Switch boasts a long lifespan of 50,000 hours, ensuring reliable performance over time. It is designed to fit a 10mm panel cut-out size and can accommodate panel thicknesses from 0.5-6.0mm. With a voltage rating of 12V and a current rating of ≤15mA, this switch is suitable for a wide range of applications.
In addition to its impressive specifications, our LED Push Button Switch also holds CQC and CE certificates, guaranteeing its quality and safety. With an IP40 protection degree (or customized), it can withstand various environmental conditions. Choose our factory-direct wholesale LED Push Button Switch for a cost-effective, reliable, and customizable solution for your circuit control needs.
|
item
|
value
|
|
Place of Origin
|
Shanghai,China
|
|
Brand Name
|
SK(Shangkai)
|
|
Model Number
|
AD12-002L12-W
|
|
voltage
|
12v
|
|
current
|
≤15mA
|
|
LED color
|
yellow or other : red,green,orange,blue
|
|
Cap color
|
yellow or other : red,green,orange,blue,black,white,gray
|
|
life
|
50000hours
|
|
Panel cut-out size
|
10mm
|
|
Panel thickness
|
0.5-6.0mm
|
|
Certificate
|
CQC CE
|
|
Protection Degree
|
IP40 or customized
|
|
Application
|
circuit control
|
Key Features
Our 12mm LED Push Button Switch stands out with its durable plastic construction, bright LED indicator light, and customizable color options for both the LED and cap. With a long lifespan of 50,000 hours and multiple certifications, it offers reliable performance and safety.
Why Choose Us?
As a factory supplier, we offer wholesale pricing on our LED Push Button Switch, ensuring cost-effectiveness for your projects. Our switch is designed to fit a wide range of panel sizes and thicknesses, making it versatile for various applications. Additionally, our commitment to quality and safety is evident in our CQC and CE certifications.
Applications
Our LED Push Button Switch is ideal for electrical equipment, industrial control, home automation, and automotive applications. Its bright LED indicator light makes it easy to identify the switch's status, while its durable construction ensures long-lasting performance in demanding environments.
