Description
High-Quality 15A 125VAC 4-Pin Momentary Push Button Switch with LED
As a factory supplier, we offer wholesale pricing on our 15A 125VAC 4-Pin Momentary Push Button Switch with LED. This switch is designed for lighting pendant hoist control and other applications where a reliable, momentary switch is needed.
Specifications
- Max. Current: 16A
- Max. Voltage: 250V AC
- Contact Resistance: ≤50MΩ
- Insulation Resistance: ≥100MΩ
- Dielectric Resistance: 1,500V 1min
- Electronic Life (cycles): 50,000
- Mechanical Life (cycles): 50,000
- Certification: CQC, CB
- Operating Temperature: -25℃ to +85℃ (-13℉ to 185℉)
- IP Code: IP40
- Size: 20×13.4mm
- Rated Voltage: 20V
Advantages
Our push button switch stands out from competitors with its high electronic and mechanical life cycles, ensuring long-lasting performance. The LED indicator provides clear visual feedback, making it ideal for use in low-light environments. Additionally, our factory-direct pricing means you get the best value for your money.
After-Sales Service
We offer comprehensive after-sales service, including technical support and warranty coverage. As a trusted supplier, we are committed to ensuring your satisfaction with our products.
| Max. Rating Current & Voltage |
16(4)A 250V AC |
| Contact Resistance | ≤50MΩ momentary push button switch for lighting |
| Insulation Resistance | ≥100MΩ |
| Dielectric Resistance | 1,500V 1min |
| Electronic life(cycles) | 10,000 push button switch 15a 125vac |
| Mechanical life(cycles) | 50,000 |
| Certification |
CQC , CB |
| Operating temperature | -25℃~+85℃ |
| IP code | IP40 push button pendant hoist control |
Why Choose Our 15A 125VAC 4-Pin Momentary Push Button Switch with LED?
Our switch is designed for durability and reliability, with a high electronic and mechanical life cycle that ensures long-lasting performance. The LED indicator provides clear visual feedback, making it ideal for use in low-light environments. Whether you're controlling lighting or a pendant hoist, our switch offers the precision and reliability you need.
What Makes Our Switch Stand Out?
Our factory-direct pricing means you get the best value for your money. Additionally, our comprehensive after-sales service, including technical support and warranty coverage, ensures your satisfaction with our products. We are committed to providing high-quality, reliable switches that meet your needs.
Applications and Compatibility
Our 15A 125VAC 4-Pin Momentary Push Button Switch with LED is suitable for a wide range of applications, including lighting control, pendant hoist control, and other industrial applications. Its compact size and IP40 protection level make it versatile and easy to integrate into your existing systems.
