Description
| Contact Resistance | ≤50mΩ |
| Insulation Resistance | ≥100mΩ |
| Dielectric Strength | 1,500V |
| Electronic Life | 50,000 cycles |
| Operating temperature | -25℃~+125℃ |
| Rating current&voltage | 16A/250VAC |
Why Choose Our Microswitch?
Our microswitch stands out with its high electrical life of 50,000 cycles, ensuring long-lasting performance. It operates reliably within a wide temperature range of -25℃ to +125℃, making it suitable for various environments. As a factory supplier, we offer competitive wholesale prices and customization services to meet your specific needs.
What Are the Key Specifications?
Our microswitch is rated at 16A/250VAC, with a contact resistance of ≤50mΩ and insulation resistance of ≥100mΩ. It has a dielectric strength of 1,500V and an IP41 rating, ensuring safety and durability. The 32mm lever and SPDT function add to its versatility.
How Can We Help You?
As a factory with over 60 senior engineers, we have the expertise to customize microswitches according to your requirements. Our 5S management ensures consistent quality, and we offer excellent after-sales service. Choose us for reliable, high-quality microswitches at wholesale prices.
