Description
Introducing our high-quality 16mm Push Button Switch, a perfect choice for electric, home appliance, and industrial control applications. As a direct factory supplier, we offer wholesale pricing on this durable, waterproof (IP65 rated) switch. It features a round head design, pin terminals, and full illumination for easy visibility. The switch is mechanical, electronic, and electromagnetic, ensuring reliable performance. With a max. rating of 3A 250V AC, it’s suitable for a wide range of uses. Our switch stands out with its low contact resistance (≤50mΩ), high dielectric strength (1500V), and wide operating temperature range (-25℃ to 85℃). It’s also CQC and CE certified, guaranteeing safety and quality. Choose us for competitive pricing, fast delivery, and excellent after-sales service.
|
contact resistance
|
≤50MΩ
|
mechanical life（cycles）
|
50000
|
|
insulation resistance
|
≥100MΩ
|
electronic life（cycles）
|
10000
|
|
dielectric strength
|
1500V
|
operating temperature
|
25T85
|
|
IP code
|
IP40
|
max.rating current & voltage
|
3A 250V AC
|
Why Choose Our Push Button Switch?
Our 16mm Push Button Switch is designed for durability and reliability, making it ideal for electric, home appliance, and industrial control applications. With its IP65 waterproof rating, it can withstand harsh environments, ensuring long-lasting performance.
What Makes Our Switch Stand Out?
Our switch features a round head design, pin terminals, and full illumination for easy visibility. It's mechanical, electronic, and electromagnetic, providing reliable operation. The low contact resistance and high dielectric strength ensure safety and efficiency.
Benefits of Buying from Us
As a factory supplier, we offer wholesale pricing, fast delivery, and excellent after-sales service. Our switch is CQC and CE certified, guaranteeing quality and safety. Choose us for a hassle-free purchasing experience.
