Description
Our switch is designed with a 3A 250V AC rating, making it suitable for a wide range of applications. With a contact resistance of ≤50mΩ and insulation resistance of ≥100MΩ, it guarantees optimal performance and safety. The switch has a dielectric resistance of 1,500V and an electronic life of 10,000 cycles, with a mechanical life of up to 50,000 cycles, ensuring longevity and reliability.
Certified by CQC and CE, our switch meets international quality standards. It operates within a temperature range of -25℃ to +85℃, making it suitable for various environments. The switch’s momentary action and 1NO switch combination provide precise control, while its red color adds a visual indicator for easy identification.
As a supplier, we pride ourselves on offering competitive pricing and excellent customer service. We offer bulk discounts for wholesalers and ensure timely delivery. Choose our 16mm Red Momentary Push Button Switch for your next project and experience the difference in quality and value.
| Max. Rating Current & Voltage |
3A 250V AC |
| Contact Resistance | ≤50mΩ electrical switch push button |
| Insulation Resistance | ≥100MΩ |
| Dielectric Resistance | 1,500V 16mm push button switch |
| Electronic life(cycles) | 10,000 |
| Mechanical life(cycles) | 50,000 momentary push button |
| Certification |
CQC , CE |
| Operating temperature | -25℃~+85℃ |
| IP code | IP65 |
Why Choose Our 16mm Red Momentary Push Button Switch?
Our 16mm Red Momentary Push Button Switch stands out for its durability, reliability, and value. With a 3A 250V AC rating and IP65 waterproof design, it's suitable for a wide range of applications. The momentary action and 1NO switch combination provide precise control, while the red color adds a visual indicator for easy identification. As a factory direct supplier, we offer wholesale pricing and excellent customer service.
What Are the Key Features of Our Switch?
Key features include a contact resistance of ≤50mΩ, insulation resistance of ≥100MΩ, and a dielectric resistance of 1,500V. It has an electronic life of 10,000 cycles and a mechanical life of up to 50,000 cycles. Certified by CQC and CE, it meets international quality standards and operates within a temperature range of -25℃ to +85℃.
How Can Our Switch Benefit Your Business?
Our switch offers high quality at competitive prices, making it ideal for wholesalers and businesses looking to save on costs without compromising on performance. As a factory direct supplier, we ensure timely delivery and excellent customer service. Choose our 16mm Red Momentary Push Button Switch for your next project and experience the difference in quality and value.
