Description
|
item
|
value
|
|
Place of Origin
|
Shanghai,China
|
|
Brand Name
|
Sk(Shangkai), yongxing
|
|
Model Number
|
YB422B-508M-2P
|
|
Type
|
Screw Terminal
|
|
Rated voltage
|
300V
|
|
Rated Current
|
16A
|
|
Contact Resistance
|
20mΩ
|
|
Insulation Resistance
|
>5000MΩ DC500V
|
|
Withstand Voltage
|
AC2000V/Min
|
|
Wire range
|
24-12AWG 2.5mm(quadratic)
|
|
Strip Length
|
6-7mm
|
|
Operating Temperature
|
-40℃~+150℃
|
|
Screw
|
M2.5steel Zinc plated
|
|
Contact
|
Brass,Tin plated
|
Why Choose Our 2 Pin 5.08mm PCB Terminal Block?
Our 2 Pin 5.08mm PCB Terminal Block stands out for its durability, reliability, and high-performance specifications. With a rated voltage of 300V and a rated current of 16A, it's designed to handle demanding electrical applications. The brass, tin-plated contacts ensure excellent conductivity, while the M2.5 steel, zinc-plated screws provide a secure and long-lasting connection. Our factory-direct supply means you get competitive pricing and fast delivery, making it an ideal choice for wholesale buyers.
Key Features of Our Terminal Block
Our terminal block features a contact resistance of just 20mΩ, ensuring minimal power loss. It has an insulation resistance greater than 5000MΩ at DC500V, providing superior electrical isolation. With a withstand voltage of AC2000V/Min, it can handle high-voltage applications with ease. The wide operating temperature range from -40℃ to +150℃ makes it suitable for use in extreme environments.
Applications and Benefits
This terminal block is perfect for electrical wiring, industrial control systems, power distribution, and automation systems. Its robust design and high-quality materials ensure reliable performance, reducing the risk of electrical failures. As a factory and supplier, we offer wholesale pricing, making it an affordable solution for large-scale projects. Choose our terminal block for a cost-effective, high-quality electrical connection solution.
