Description
|
item
|
value
|
|
Place of Origin
|
Shanghai,China
|
|
Brand Name
|
Sk(shangkai) yongxing
|
|
Model Number
|
LA133-A1.Y2S-K11
|
|
Protection Level
|
IP40 IP65 IP67
|
|
Max. Current
|
10A
|
|
Max. Voltage
|
660 VAC
|
|
Rated Insulation Voltage
|
660v ac
|
|
Rated Thermal Current
|
10A
|
|
Max.insulation voltage
|
2500 V/min
|
|
Usage Category
|
AC-15 DC-13
|
|
Mechanical Life
|
1000,000
|
|
Operation frequency
|
1200 cycles/h
|
|
Electrical life for AC-15
|
600000 cycles
|
|
Electrical life for DC-13
|
250000 cycles
|
|
Mounting Hole Size
|
22mm Diameter
|
Why Choose Our 2-Position Ignition Key Switch?
Our 2-position ignition key switch stands out for its durability, reliability, and versatility. With IP40, IP65, and IP67 protection levels, it's built to withstand harsh conditions. The switch's high current and voltage ratings ensure it meets demanding electrical standards, making it ideal for scooters, elevators, and emergency door systems.
What Makes Our Switch Different?
Unlike competitors, our switch offers multiple combinations (1NO1NC, 1NO, 2NO2NC, 2NO) to suit diverse applications. Its long mechanical and electrical life guarantee extended performance, reducing maintenance costs. As a factory-direct supplier, we offer competitive pricing and excellent customer service.
How Easy Is It to Install and Use?
Installation is a breeze with our 22mm diameter mounting hole size. The switch's intuitive design ensures easy operation, even for non-technical users. Plus, our comprehensive customer support is always available to assist with any questions or concerns.
