Description
Product Specifications:
– Model Number: KCD8-11-CB1A-W-W-03
– Max. Current: 6A (also available in 10A)
– Max. Voltage: 250V
– Circuit: ON-OFF
– Mechanical Life: 100,000 cycles
– Electrical Life: Min 10,000 Cycles
– Color: White
– Pins: 2-pin
– Material: PA66
– Insulation Resistance: 100M Min
– Contact Resistance: 50m Max
– Dielectric Strength: 1500VAC 1 Minute
Product Advantages:
Our rocker switch stands out with its durable PA66 material, ensuring long-lasting performance. With a mechanical life of 100,000 cycles and an electrical life of at least 10,000 cycles, it offers reliability that surpasses many competitors. The white finish adds a touch of elegance to any device.
Customization and Support:
If you require a specific quantity or have unique customization needs, our factory is equipped to meet your demands. We have an independent plant, injection workshop, and advanced experimental equipment, along with over 60 senior engineers. All workshops adhere to 5S and 5m management standards, ensuring top-notch quality control.
As a factory supplier, we offer competitive wholesale prices and excellent after-sales service. Choose us for your rocker switch needs and experience the difference in quality and service.
|
KCD8-11-CB1A-W-W-03
|
||
|
Max.Rating Current&Voltage：
|
6A 250V
|
|
|
Circuit：
|
ON OFF
|
|
|
electronic life：
|
10,000 cycles
|
|
|
Actuator color：
|
White
|
|
|
Housing color：
|
white
|
|
Why Choose Our 20.2mm White Rocker Switch?
Our 20.2mm White Rocker Switch is designed with durability and performance in mind. Made from high-quality PA66 material, it ensures long-lasting use and reliable operation. The ON-OFF function provides straightforward control, making it ideal for a variety of electrical devices.
What Makes Our Switch Stand Out?
With a mechanical life of 100,000 cycles and an electrical life of at least 10,000 cycles, our switch offers unmatched reliability. The sleek white finish adds a touch of sophistication to any device, making it a popular choice among customers.
Can We Customize the Switch?
Absolutely! As a factory supplier, we have the capability to customize the rocker switch to meet your specific requirements. Whether you need a different color, size, or functionality, our team of engineers is ready to assist you.
