Description
The switch features a 3-pin design, compatible with both 24V and 220V systems, and includes a bright LED indicator for easy visibility. With a maximum current rating of 3A and a voltage rating of 250VAC, this switch is built to handle demanding electrical loads. The plastic lamp body ensures durability and longevity, while the IP40 protection level offers reliable performance in various environments.
Our switch stands out from the competition with its exceptional mechanical life of 200,000 cycles for momentary operation and 50,000 cycles for alternate operation. The electronic life is also impressive, with 50,000 cycles for momentary and 25,000 cycles for alternate. Additionally, the switch operates within a wide temperature range of -5℃ to +75℃, making it suitable for use in diverse climates.
As a factory supplier, we are committed to providing excellent customer service and after-sales support. Our team is always available to answer any questions and assist with your purchasing needs. Choose our LED Push Button Switch for reliable performance, durability, and value.
|
Max. Rating Current & Voltage(Resistive Load) |
3A/250VAC |
|
Contact Resistance |
≤50mΩ |
|
Insulation Resistance |
≥100mΩ |
|
Dielectric Strength |
1500V |
|
Electronic Life(cycles) |
Moment: 50,000 Alternate: 25,000 |
|
Mechanical Life(cycles) |
Momentary:200,000 Alternate:50,000 |
|
Operating temperature |
-5℃ ~ +75℃ |
|
IP code |
IP40 |
Why Choose Our LED Push Button Switch?
Our LED Push Button Switch offers unmatched durability, with a mechanical life of up to 200,000 cycles for momentary operation. The bright LED indicator ensures easy visibility, making it ideal for use in various applications.
What Makes Our Switch Stand Out?
Our switch is built to handle demanding electrical loads, with a maximum current rating of 3A and a voltage rating of 250VAC. The plastic lamp body provides durability, while the IP40 protection level ensures reliable performance in diverse environments.
Why Buy From Us?
As a factory direct supplier, we offer wholesale pricing on our high-quality LED Push Button Switch. Our commitment to excellent customer service and after-sales support ensures a smooth purchasing experience. Choose us for reliable performance, durability, and value.
