Description
**Key Specifications**:
– **Place of Origin**: Shanghai, China
– **Brand Name**: SK (Shangkai) Yongxing
– **Protection Level**: IP40
– **Max. Current**: 10(3)A / 16(4)A
– **Max. Voltage**: 250VAC
– **Contact Resistance**: 50mΩ Max
– **Insulation Resistance**: 100MΩ Min
– **Dielectric Strength**: 1500V 1min
– **Mechanical Life**: 20,000 cycles
– **Electrical Life**: 10,000 cycles
– **Operating Temperature**: -25°C to +85°C
– **Certificate**: CQC, CE, CB
– **Mounting Hole Size**: 22mm Diameter
– **Panel Thickness**: 1.5~3mm
**Product Advantages**:
– **High Durability**: With a mechanical life of 20,000 cycles and an electrical life of 10,000 cycles, this switch is built to last.
– **Wide Temperature Range**: Operates efficiently in temperatures ranging from -25°C to +85°C, making it suitable for various environments.
– **Safety Certifications**: Complies with CQC, CE, and CB standards, ensuring safety and reliability.
– **LED Indicator**: Equipped with an LED indicator for easy status identification.
– **Self-Locking Mechanism**: Provides a secure and reliable connection, preventing accidental disconnections.
**After-Sales Service**:
We offer comprehensive after-sales service, including technical support and warranty coverage. Our factory-direct pricing ensures you get the best value for your money.
|
item
|
value
|
|
Place of Origin
|
Shanghai,China
|
|
Brand Name
|
SK(Shangkai) yongxing
|
|
Model Number
|
KA22-11L-CBA-BC12-G-S1
|
|
Protection Level
|
IP40
|
|
Max. Current
|
10(3)A / 16(4)A
|
|
Max. Voltage
|
250VAC
|
|
Contact Resistance
|
50m Max
|
|
Insulation Resistance
|
100M Min
|
|
Dielectric Strength
|
1500V 1min
|
|
Mechanical Life
|
20000
|
|
Electrical Life
|
10000
|
|
Operating temperature
|
-25℃~+85℃
|
|
Certificate
|
CQC CE CB
|
|
Mounting Hole Size
|
22mm Diameter
|
|
Panel thickness
|
1.5~3mm
|
Why Choose Our 22mm 12V LED Self-Locking Push Button Switch?
Our switch stands out with its high durability, wide operating temperature range, and safety certifications. The self-locking mechanism ensures a secure connection, while the LED indicator provides easy status identification. Perfect for industrial control, home automation, and more.
What Makes Our Product Different?
Unlike other switches on the market, ours offers a longer mechanical and electrical life, ensuring reliability over time. The factory-direct pricing and wholesale options make it a cost-effective choice for bulk purchases.
How Can I Benefit from Buying in Bulk?
As a factory supplier, we offer competitive wholesale pricing for bulk orders. This allows you to save money while ensuring you have a steady supply of high-quality switches for your projects or business needs.
