Description
This push button switch features a momentary latching mechanism with an integrated LED light, providing clear visual indication of its status. With a max current of 10A and max voltage of 660 VAC, it’s suitable for both AC and DC circuits. The switch is rated for 1 million mechanical cycles and up to 600,000 electrical cycles (AC-15) or 250,000 electrical cycles (DC-13), ensuring long-lasting reliability.
Our switch is available in various lamp voltages, including 6V, 12V, 24V, 36V, 48V, 110V, 220V, and 380V, making it adaptable to different power requirements. It also offers multiple IP protection levels (IP40, IP41, IP53, IP65, IP67), ensuring protection against dust and moisture in various environments.
One of the key differentiators of our product is its high mechanical and electrical life, which outperforms many competitors in the market. Additionally, our factory direct supply ensures consistent quality and fast delivery times.
We stand behind our products with excellent customer service and support. Whether you’re a wholesaler, distributor, or end-user, we’re here to help you find the right solution for your needs.
|
item
|
value
|
|
Place of Origin
|
Shanghai,China
|
|
Brand Name
|
Sk(shangkai) yongxing
|
|
Protection Level
|
IP40 IP65 IP67
|
|
Max. Current
|
10A
|
|
Max. Voltage
|
660 VAC
|
|
Rated Insulation Voltage
|
660v ac
|
|
Rated Thermal Current
|
10A
|
|
Max.insulation voltage
|
2500 V/min
|
|
Usage Category
|
AC-15 DC-13
|
|
Mechanical Life
|
1000,000
|
|
Operation frequency
|
1200 cycles/h
|
|
Electrical life for AC-15
|
600000 cycles
|
|
Electrical life for DC-13
|
250000 cycles
|
|
Mounting Hole Size
|
22mm Diameter
|
|
Lamp Voltage
|
6v 12v 24v 36v 48v 110v 220v 380v
|
Product Overview
Our 22mm Momentary Latching LED Push Button Switch is a high-quality electronic component designed for durability and versatility. It's perfect for industrial control, automation systems, and electrical panels, offering reliable performance in a wide range of applications.
Key Features
This switch features a momentary latching mechanism with an integrated LED light for clear visual indication. With a max current of 10A and max voltage of 660 VAC, it's suitable for both AC and DC circuits. The high mechanical and electrical life ensures long-lasting reliability, outperforming many competitors in the market.
Why Choose Us?
As a factory direct supplier, we offer wholesale pricing on this popular product, ensuring you get the best value for your money. We stand behind our products with excellent customer service and support, making us the ideal choice for wholesalers, distributors, and end-users alike.
