Description
250V 7-Position Rotary Switch – Factory Direct Wholesale Supplier
Introducing our high-quality 250V 7-position rotary switch, perfect for electric heaters, pedestal fans, and more. As a factory supplier, we offer competitive wholesale prices and ensure top-notch quality.
Product Specifications:
- Model: RS3-13
- Max. Rating Current & Voltage: 6.5A/250V AC, 13A/125V AC
- Contact Resistance: ≤50mΩ
- Insulation Resistance: ≥100MΩ
- Dielectric Resistance: 1500V
- Electronic Life: 10,000 cycles
- Mechanical Life: 100,000 cycles
- Operating Temperature: T50
- IP Level: IP41
- Color: Black
- Poles: SP (Single Pole)
Product Advantages:
Our rotary switch stands out with its durability, precision, and wide range of applications. The high dielectric resistance ensures safety, while the long mechanical and electronic life guarantees reliability. Perfect for bulk orders, we offer factory-direct pricing and excellent after-sales service.
Applications:
Ideal for electric heaters, pedestal fans, and other electrical appliances requiring precise control.
Why Choose Us:
As a factory supplier, we ensure quality, affordability, and timely delivery. Our wholesale options make it easy for you to stock up on this essential component.
|
Max. Rating Current&Voltage(Resistive load) |
6.5A/250V AC , 13A/125V AC |
| Contact Resistance of hot plate Rotary Switch | ≤50m Ω |
| Insulation Resistance | ≥100MΩ |
| Dielectric Resistance 4 position Rotary Switch | 1500V |
| Electronic life(cycles) | 10,000 |
| Operating temperature Rotary Switch | T150 |
| Certification |
CQC , Rohs |
Why Choose Our 250V 7-Position Rotary Switch?
Our rotary switch is designed for precision and durability, making it ideal for a wide range of electrical applications. With a high dielectric resistance and long mechanical life, it ensures safe and reliable operation.
What Are the Key Specifications?
Key specifications include a max. rating current of 6.5A/250V AC and 13A/125V AC, a contact resistance of ≤50mΩ, and an insulation resistance of ≥100MΩ. It also features a 1500V dielectric resistance and an electronic life of 10,000 cycles.
How Can I Benefit from Buying Wholesale?
As a factory supplier, we offer competitive wholesale prices, making it easy for you to stock up on this essential component. Our bulk order options ensure you get the best value for your money.
