Description
Our rocker switch stands out with its black housing and red rocker, providing a clear visual indication of its ON-OFF status. It boasts a mechanical life of 50,000 cycles and an electronic life of 10,000 cycles, ensuring long-lasting reliability. With a contact resistance of ≤50mΩ and an insulation resistance of ≥1000MΩ, it guarantees safe and efficient operation.
This switch is designed for use in a wide temperature range (0~55℃, 0~85℃, 0~105℃) and features an IP65 rating, making it suitable for various environments. It is certified by CQC, CE, ROHS, CB, and ENEC17, ensuring compliance with international standards.
As a factory supplier, we offer competitive pricing and excellent customer service. Whether you need a single unit or bulk quantities, we are here to meet your needs. Contact us today to learn more about our wholesale options.
|
item
|
value
|
|
Place of Origin
|
Shanghai, China
|
|
Brand Name
|
SK(shangkai) Yongxing
|
|
Model Number
|
KCD1-11N-CA5C-B-R-01-AC220
|
|
Current Rating
|
16A
|
|
Voltage Rating
|
250V AC
|
|
Mechanical Life
|
50,000 Cycles
|
|
Contact Resistance
|
≤50mΩ
|
|
Insulation Resistance
|
≥1000MΩ
|
|
Dielectric Strength
|
1500VAC 1 Minute
|
|
Electronic Life (cycles)
|
10,000
|
|
Certificate
|
CQC CE CB ENEC17 ROHS
|
|
Circuit
|
SPST illuminated
|
|
Dimension Code
|
A5 28x11mm
|
|
Contact Piece Code
|
C 6.3X0.8X10mm standard
|
|
Lamp voltage
|
AC220V
|
Product Overview
Our 28x11mm 3-pin 16A 250VAC rocker switch is a versatile and reliable component suitable for automotive, electric equipment, and industrial applications. Its durable construction and clear visual indication make it a top choice for various projects.
Key Features
With a mechanical life of 50,000 cycles and an electronic life of 10,000 cycles, our rocker switch offers long-lasting reliability. It features a black housing with a red rocker for easy ON-OFF status identification. The switch is designed for use in a wide temperature range and boasts an IP65 rating, ensuring durability in various environments.
Why Choose Us?
As a factory supplier, we offer competitive wholesale pricing on our high-quality rocker switches. We are committed to providing excellent customer service and ensuring that our products meet international standards. Whether you need a single unit or bulk quantities, we are here to meet your needs.
