Description
| Material | |
| Contact | Brass, Tin Plated |
| Housing | PA66 |
| Color | Green 10 pin connectors |
| Environmental | |
| Operating temperature | -40°C ~ 150°C |
| Short-time temperature | +250°C for 5 sec |
| Electrical | |
| Rated voltage | 300V |
| Rated current | 16A screw clamp wire connectors |
| Contact resistance | 20mΩ |
| Insulation resistance | >5000MΩ DC500V |
| Withstanding voltage | AC2000V/Min terminal connectors |
Why Choose Our PCB Pluggable Terminal Blocks?
Our PCB pluggable terminal blocks are designed for reliability and ease of use. With a 3.81mm pitch and 12A rated current, they are perfect for a wide range of electrical connections. The green PA66 housing not only provides durability but also ensures a clear color identification. As a factory supplier, we offer wholesale pricing, making our terminal blocks an affordable choice for your projects.
What Makes Our Terminal Blocks Stand Out?
Our terminal blocks feature brass, tin-plated contacts for excellent conductivity and corrosion resistance. They have a high insulation resistance of over 5000MΩ at DC500V and a low contact resistance of just 20mΩ, ensuring efficient electrical performance. Additionally, they can withstand temperatures from -40°C to 150°C, making them suitable for harsh environments.
How Can Our Terminal Blocks Benefit Your Business?
By choosing our wholesale terminal blocks, you benefit from factory-direct pricing, reducing your costs. Our pluggable design simplifies installation and maintenance, saving you time and effort. With a wide range of pole configurations and conductor sizes available, our terminal blocks can meet the diverse needs of your industrial or automotive applications.
