Description
Wholesale 3A 250V 12mm Push Button Switch – Factory Direct Supply
Introducing our high-quality 3A 250V push button switch, available in both 3-pin and 5-pin configurations, with a compact 12mm design. This switch is perfect for a wide range of applications, offering reliable performance and durability. As a factory supplier, we offer wholesale pricing and direct shipping, ensuring you get the best value for your money.
Product Specifications:
- Max. Rating Current & Voltage: 3A 250V AC
- Contact Resistance: ≤50mΩ
- Insulation Resistance: ≥100MΩ
- Dielectric Resistance: 1,500V
- Electronic Life: Momentary: 50,000 cycles, Alternate: 25,000 cycles
- Mechanical Life: Momentary: 200,000 cycles, Alternate: 50,000 cycles
- Certification: CQC, CE
- Operating Temperature: -5℃~+75℃
- IP Code: IP40
- LED Indicator: Yes, available in 2V, 6V, 12V, 24V, 110V, 220V
- Switch Combination: 1NO1NC
- Panel Cutout: 12mm
Product Advantages:
Our push button switch stands out from the competition with its high-quality construction, reliable performance, and competitive pricing. As a factory supplier, we can offer customizations and bulk discounts, making it an ideal choice for businesses looking for a cost-effective solution.
After-Sales Service:
We are committed to providing excellent after-sales service. If you encounter any issues with our product, please contact us, and we will do our best to resolve them promptly.
| Max. Rating Current & Voltage (Resistive Load) |
3A 250V AC indicator light |
| Contact Resistance | ≤50mΩ |
| Insulation Resistance | ≥100MΩ 220 volt led indicator lights |
| Dielectric Resistance | 1,500V |
| Electronic life(cycles) | Momentary:50,000 Alternate:25,000 |
| Mechanical life(cycles) | Momentary:200,000 Alternate:50,000 |
| Certification |
CQC , CE |
| Operating temperature | -5℃~+75℃ |
| IP code | IP40 |
Why Choose Our Push Button Switch?
Our push button switch is designed for reliability and durability, making it an ideal choice for a wide range of applications. With its high-quality construction and competitive pricing, it offers excellent value for money.
Key Features:
Our switch features a compact 12mm design, 3A 250V rating, and both momentary and alternate action options. It also includes an LED indicator for easy status monitoring.
Applications:
This switch is perfect for industrial control systems, home appliances, and automotive applications. Its versatility and reliability make it a popular choice among businesses and consumers alike.
