Description
Our Spring Terminal Block boasts a rated voltage of 300V and a rated current of 10A, making it suitable for a wide range of applications. With a contact resistance of just 20mΩ and an insulation resistance exceeding 5000MΩ at DC500V, it guarantees excellent electrical performance. The terminal block can withstand AC2000V/Min, ensuring safety under high voltage conditions.
Operating temperature ranges from -40℃ to +150℃, making it suitable for extreme environments. The contacts are made of brass and tin-plated for enhanced conductivity and corrosion resistance. Our product is CQC certified, ensuring quality and compliance with industry standards.
What sets our terminal block apart is its spring-loaded design, which allows for quick and easy wire insertion without the need for screws. This not only saves time but also reduces the risk of damage during installation. Additionally, as a factory supplier, we offer wholesale pricing, making it an economical choice for bulk purchases.
We provide comprehensive after-sales service, including technical support and warranty coverage, to ensure your satisfaction. Choose our 5.08mm Spring Terminal Block for a reliable, efficient, and cost-effective connection solution.
|
item
|
value
|
|
Place of Origin
|
Shanghai,China
|
|
Brand Name
|
Sk(Shangkai), yongxing
|
|
Model Number
|
YX222-508-06P
|
|
Type
|
Spring Terminal
|
|
Rated voltage
|
300V
|
|
Rated Current
|
10A
|
|
Contact Resistance
|
20mΩ
|
|
Insulation Resistance
|
>5000MΩ DC500V
|
|
Withstand Voltage
|
AC2000V/Min
|
|
Operating Temperature
|
-40℃~+150℃
|
|
Contact
|
Brass,Tin plated
|
|
Poles
|
2~16 poles
|
|
Certificate
|
CQC
|
Why Choose Our 5.08mm Spring Terminal Block?
Our 5.08mm Spring Terminal Block offers a spring-loaded design for quick and easy wire insertion, eliminating the need for screws. This not only saves time but also reduces the risk of damage during installation. With a rated voltage of 300V and a rated current of 10A, it is suitable for a wide range of applications, ensuring reliable and efficient electrical connections.
What Are the Key Features of Our Terminal Block?
Key features include a contact resistance of just 20mΩ, an insulation resistance exceeding 5000MΩ at DC500V, and the ability to withstand AC2000V/Min. The contacts are made of brass and tin-plated for enhanced conductivity and corrosion resistance. Additionally, it operates in temperatures ranging from -40℃ to +150℃, making it suitable for extreme environments.
Why Buy from Us as a Factory Supplier?
As a factory supplier, we offer wholesale pricing, making our 5.08mm Spring Terminal Block an economical choice for bulk purchases. We provide comprehensive after-sales service, including technical support and warranty coverage, to ensure your satisfaction. Choose us for a reliable, efficient, and cost-effective connection solution.
