Description
Product Specifications:
- Material: Contact: Brass, Tin Plated; Housing: PA66, UL94V-0
- Color: Green
- Operating Temperature: -40°C to 150°C
- Short-time Temperature: +250°C for 5 sec
- Rated Voltage: 300V
- Rated Current: 16A
- Contact Resistance: 20mΩ
- Insulation Resistance: >5000MΩ DC500V
- Withstanding Voltage: AC2000V/1Min
- Number of Contacts: 1 – 10
- Conductor Size: 21 – 30 AWG
- Poles: 2-3 (2 pins)
Product Advantages:
- High-quality materials ensure long-lasting performance.
- Wide operating temperature range makes it suitable for various environments.
- Excellent electrical properties, including high insulation resistance and withstanding voltage.
- Easy to install and use, saving time and effort.
After-sales Service: We provide comprehensive after-sales service, including technical support and product warranties. Our team is always ready to assist you with any questions or concerns you may have.
Choose our factory-direct PCB Wire End Stopper Spade Terminal Block for a reliable and cost-effective solution.
| Material | |
| Contact | Brass, Tin Plated |
| Housing | PA66 ,UL94V-0 |
| Color | Green pa66 terminal connector |
| Environmental | |
| Operating temperature | -40°C ~ 150°C |
| Short-time temperature | +250°C for 5 sec |
| Electrical | |
| Rated voltage | 300V connector blocks |
| Rated current | 16A 2 pins connector |
| Contact resistance | 20mΩ |
| Insulation resistance | >5000MΩ DC500V |
| Withstanding voltage | AC2000V/1Min |
Why Choose Our 5mm PCB Wire End Stopper Spade Terminal Block?
Our 5mm PCB Wire End Stopper Spade Terminal Block stands out for its high-quality materials, including brass contacts with tin plating and a PA66, UL94V-0 housing. These materials ensure excellent electrical conductivity and durability, making it ideal for telecom and industrial applications. The wide operating temperature range (-40°C to 150°C) and high withstanding voltage (AC2000V/1Min) further enhance its reliability.
What Are the Key Features of This Terminal Block?
Key features include a rated voltage of 300V, a rated current of 16A, and a contact resistance of just 20mΩ. It also boasts an insulation resistance of over 5000MΩ DC500V, ensuring safe and efficient electrical connections. The terminal block is designed for easy installation and use, saving you time and effort.
How Does Our Factory-Direct Supply Benefit You?
As a factory supplier, we offer competitive wholesale prices without compromising on quality. Our direct supply chain ensures that you receive the product quickly and efficiently. Additionally, we provide comprehensive after-sales service, including technical support and product warranties, giving you peace of mind with your purchase.
