Description
|
Max. Rating Current & Voltage(Resistive Load) |
6A 250V AC |
|
Contact Resistance |
≤50mΩ |
|
Insulation Resistance |
≥100mΩ |
|
Dielectric Strength |
1500V |
|
Electronic Life(cycles) |
10000cycles |
|
Operating temperature |
T125 |
|
certifications |
CQC ENEC17 |
|
Contact leg |
Brass T=0.8mm |
|
Contact |
Silver alloy |
|
Terminals |
Brass T=0.8mm |
|
Case |
PA66 |
|
Gear |
PA66 |
Why Choose Our 6A 250V AC Oven Rotary Switch?
Our 6A 250V AC Oven Rotary Switch stands out for its durability, reliability, and performance. With a max. rating current of 6A and voltage of 250V AC, it's perfectly suited for ovens and other home appliances. The switch's long electronic life (50,000 cycles) and high mechanical life (100,000 cycles) ensure it will last longer than many competitors, reducing replacement costs.
What Makes Our Switch Different?
Our switch is made of premium materials, including brass terminals and a silver alloy contact, ensuring superior conductivity and durability. The PA66 case and gear provide excellent heat resistance and mechanical strength. Additionally, as a factory supplier, we offer wholesale prices, making it a cost-effective choice for bulk purchases.
What Are the Key Features?
Key features include a contact resistance of ≤50mΩ, insulation resistance of ≥100mΩ, and a dielectric strength of 1500V, ensuring safety and reliability. The switch is also certified by CQC and ENEC17, meeting international safety standards. Choose our switch for peace of mind and optimal performance.
