Description
Key Features:
– Max. Current: 3A
– Max. Voltage: 250V AC
– Mechanical Life: 200,000 cycles
– Insulation Resistance: ≥100MΩ
– Dielectric Resistance: 1,500V for 1 minute
– Operating Temperature: -25℃ to 55℃
– Electronic Life: 25,000 cycles
– Certification: CQC ENEC17
Our AX16 Rotary Switch stands out from competitors with its long mechanical life, high insulation and dielectric resistance, and wide operating temperature range. As a factory supplier, we offer wholesale pricing and excellent customer service, ensuring you get the best value for your money. Perfect for electrical appliances, control panels, and more, this switch is a must-have for any business looking for reliable, high-quality components.
|
Max. Rating Current&Voltage(Resistive load) |
6A 250V AC |
| Contact Resistance of hot plate Rotary Switch | ≤50m Ω |
| Insulation Resistance | ≥100MΩ |
| Dielectric Resistance 4 position Rotary Switch | 1500V |
| Electronic life(cycles) | 10,000 |
| Operating temperature Rotary Switch | T125 |
| Certification |
CQC ENEC17 |
Key Features and Advantages
Our AX16 2-Position Rotary Switch is designed for durability and reliability, with a mechanical life of 200,000 cycles and high insulation and dielectric resistance. It can handle a maximum current of 3A and voltage of 250V AC, making it suitable for a wide range of applications.
Why Choose Our Product?
As a factory supplier, we offer wholesale pricing and excellent customer service. Our AX16 Rotary Switch stands out from competitors with its long mechanical life, high resistance values, and wide operating temperature range. It's perfect for electrical appliances, control panels, and more.
Certification and Quality Assurance
Our AX16 Rotary Switch is certified by CQC ENEC17, ensuring its quality and safety. We are committed to providing high-quality products that meet or exceed industry standards, giving you peace of mind in your purchase.
