Description
|
item
|
value
|
|
Place of Origin
|
Shanghai,China
|
|
Brand Name
|
SK(Shangkai)
|
|
Model Number
|
KA5-5-NO-SS
|
|
Protection Level
|
IP40
|
|
Max. Current
|
1A
|
|
Max. Voltage
|
250V AC
|
|
Contact Resistance
|
50mΩ Max.
|
|
Insulation Resistance
|
100MΩ Min.
|
|
Dielectric Strength
|
1500V
|
|
Mechanical Life
|
50000 Times
|
|
Electrical Life
|
100000 Times
|
|
Operating temperature
|
-25℃~+55℃
|
|
Protection Class
|
IP40
|
|
Mounting Hole Size
|
12mm
|
|
Function
|
NC,NO
|
|
Panel Thickness
|
0.4-0.6, 0.8-2.4, 1.4-1.6
|
Why Choose Our Push Button Switch?
Our push button switch is a top choice for refrigerator doors due to its high quality, reliability, and versatility. Made from durable plastic, it features a normally open (NO) and normally closed (NC) function, making it suitable for a variety of electrical control applications. With a maximum current of 1A and a maximum voltage of 250V AC, it can handle most standard loads.
What Are the Key Features?
Key features include a contact resistance of 50mΩ Max., ensuring efficient electrical contact, and an insulation resistance of 100MΩ Min., providing excellent electrical insulation. The dielectric strength of 1500V guarantees safety under high voltage conditions. With a mechanical life of 50,000 times and an electrical life of 100,000 times, our switch is built to last.
Why Buy From Us?
As a factory-direct supplier, we offer competitive pricing and reliable service. Our switches are manufactured in Shanghai, China, to the highest standards. Choose us for quality, value, and peace of mind. Perfect for refrigerator doors and other electrical control applications.
