Wholesale Factory Direct Door Switch – High Quality Momentary Push Button

Category: Tags: , ,
100 - 1,999  pieces
$0.17

2,000 - 4,999  pieces
$0.15

>= 5,000  pieces
$0.13
0 reviews

Factory Direct Door Switch – Wholesale, High Quality, Durable

Clean All

Description

Our factory-direct Door Switch is a high-quality momentary push button switch, perfect for cabinets, refrigerators, and more. With a contact resistance of ≤50MΩ and insulation resistance of ≥100MΩ, it ensures reliable performance. The switch has an electronic life of 10,000 cycles and a mechanical life of 50,000 cycles, offering exceptional durability. It operates within a temperature range of -25°C to +55°C and withstands a dielectric strength of 1500V. Available in black, white, blue, and gray cap colors, it fits a 12mm size and is rated for 16A at 250V AC. Our switch is made of plastic, featuring a rotary head and pin terminals, with an IP40 rating and a 1NO1NC switch combination. As a direct supplier, we offer wholesale pricing and excellent customer service, ensuring your satisfaction with every purchase.
contact resistance
≤50MΩ
electronic life（cycles）
10000
insulation resistance
≥100MΩ
mechanical life（cycles）
50000
dielectric strength
1500V
operating temperature
-25℃ to +55℃

Electronic component product image for cross-border e-commerceElectronic device product shot for e-commerce website


Why Choose Our Door Switch?

Our Door Switch stands out for its high quality and durability. With a long electronic and mechanical life, it ensures reliable performance over time. The wide operating temperature range and high dielectric strength make it suitable for various applications, from home appliances to industrial control.

Key Features and Benefits

Our switch is factory-direct, meaning you get wholesale pricing without compromising on quality. The plastic material and rotary head design offer ease of use and installation. The 1NO1NC switch combination provides flexibility in your applications.

Applications and Compatibility

Perfect for cabinets, refrigerators, and other home appliances, our Door Switch is compatible with a wide range of devices. Its IP40 rating ensures protection against dust, making it ideal for industrial environments as well. Choose our switch for a reliable and cost-effective solution.

Push Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch Customized

Additional information

Max. Current

16A
Max. Voltage

250V AC
Place of Origin

Shanghai, China
Brand Name

Yongxing
Model Number

KA5
LED

NO
Application

Home Appliance, Electric, Industrial Control
Material

plastic
Structure

Electronic, Mechanical, Electromagnetic
Head Type

Rotary Head
Terminal Type

Pin terminal
Whether the smart

NO
IP level

IP40
Switch Combination

1NO1NC
Cap colour

Black, White, Blue, Gray
Electronic life

10000cycles
Operating temperature

T55
Contact Resistance

≤50MΩ start stop engine switch button
Insulation Resistance

≥100MΩ snap round button
Dielectric Resistance

1500V
Max. Rating Current & Voltage

16A 125VAC/10A 250VAC T125
Name

T55 2pin volume on-off electrical inching refrigerator door switch
