Description
|
item
|
value
|
|
Place of Origin
|
Shanghai,China
|
|
Brand Name
|
SK(shangkai) yongxing
|
|
Model Number
|
KW11-12-CAA-B
|
|
Max. Current
|
3A micro switch
|
|
Max. Voltage
|
250V micro switch
|
|
Operating Temperature
|
-25℃~+125℃
|
|
Protection Level
|
IP40 IP65 micro switch
|
|
Contact Resistance
|
≤50mΩ
|
|
Insulation Resistance
|
≥100MΩ
|
|
Dielectric Strength
|
1500V
|
|
Electrical life
|
50,000
|
|
Operating Temperature Range
|
-25℃~+125℃ 25t125 micor switch
|
|
Lever type
|
roll lever micro switch
|
|
Lever Length
|
15mm
|
|
Certification
|
CQC ENEC
|
|
Protection Degree
|
IP40, IP65 is also available micro switch
|
|
Color
|
Black
|
Why Choose Our IP65 Waterproof Micro Switch?
Our IP65 waterproof micro switch is designed to withstand harsh environments, making it ideal for kids scooters and other outdoor applications. With a high current and voltage rating, it ensures reliable performance under various conditions. The simulated roller lever design and precise lever length provide accurate control, enhancing user experience.
What Makes Our Micro Switch Stand Out?
Our micro switch stands out due to its high-quality construction, rigorous testing, and compliance with international standards. It offers a long electrical life, reducing the need for frequent replacements. As a factory-direct supplier, we can offer competitive pricing and bulk discounts, making it a cost-effective choice for manufacturers and retailers.
What Are the Key Features of Our Micro Switch?
Key features include IP65 waterproof rating, 3A maximum current, 250V maximum voltage, and an operating temperature range of -25℃ to +125℃. It also has a low contact resistance, high insulation resistance, and strong dielectric strength, ensuring safety and reliability. The switch is certified by CQC and ENEC, guaranteeing its quality and performance.
