Description
|
contact resistance
|
≤50MΩ
|
mechanical life（cycles）
|
50000
|
|
insulation resistance
|
≥100MΩ
|
electronic life（cycles）
|
10000
|
|
dielectric strength
|
1500V
|
operating temperature
|
25T85
|
|
IP code
|
IP65
|
max.rating current & voltage
|
3A 250V AC
|
Key Features
Our Waterproof Push Button Switch is designed with a 3A 250V AC rating, making it suitable for a wide range of electrical applications. The IP65 protection level ensures it can withstand dust and water, providing reliable performance even in harsh conditions.
Advantages
With a mechanical life of 50,000 cycles and an electrical life of 100,000 cycles, our switch offers exceptional durability. The low contact resistance and high insulation resistance guarantee stable electrical connections. Its compact 16MM size allows for easy installation in various devices.
Why Choose Us
As a factory supplier, we offer wholesale prices, making our Waterproof Push Button Switch a cost-effective choice. We provide excellent after-sales service, ensuring you have a smooth purchasing experience. Choose our switch for its quality, reliability, and affordability.
