Description
|
contact resistance
|
≤50MΩ
|
electronic life（cycles）
|
10000
|
|
insulation resistance
|
≥100MΩ
|
operating temperature
|
-25℃ to +55℃
|
|
dielectric strength
|
1500V AC 1min
|
IP code
|
IP40
|
Why Choose Our KAD Push Button Switch?
Our KAD 250V AC 1A Yellow Momentary Push Button Switch stands out for its durability, reliability, and versatility. With a plastic construction, it is lightweight and corrosion-resistant, making it ideal for a variety of applications. The square head design and pin terminal ensure easy installation. The IP40 rating provides protection against dust and water, while the 10,000 cycle electronic life and 50,000 cycle mechanical life guarantee longevity.
Key Features and Benefits
This switch offers a maximum current of 1A and a maximum voltage of 250VAC, making it suitable for electric, home appliance, and industrial control uses. The insulation resistance is ≥100mΩ, and the contact resistance is ≤50mΩ, ensuring excellent performance. Certified by CQC and CE, it meets international safety standards, providing peace of mind.
Factory Direct Pricing and Support
As a factory supplier, we offer wholesale pricing and reliable customer support. Our switches are designed and manufactured to the highest standards, ensuring quality and performance. Choose our KAD Push Button Switch for competitive pricing, exceptional quality, and outstanding service.
