Wholesale KCD1 Rocker Switch Supplier – 16A 250VAC Factory Direct

Category: Tags: , ,
100 - 4,999  pieces
$0.22

5,000 - 15,999  pieces
$0.21

>= 16,000  pieces
$0.19
0 reviews

Wholesale KCD1 Rocker Switch Supplier – 16A 250VAC Factory Direct

Description

Our KCD1 Rocker Switch is a high-quality electronic component designed for appliances. As a factory direct supplier, we offer wholesale pricing on this SPST, 2-pin, on-off switch with no light. Rated at 16A and 250VAC, it meets CE, UL, CQC, CB, ENEC17, and ROHS standards, ensuring safety and reliability. With a mechanical life of 50,000 cycles and an electronic life of 10,000 cycles, it outperforms many competitors. The switch features a contact resistance of ≤50mΩ, insulation resistance of ≥1000MΩ, and dielectric strength of 1500VAC for 1 minute. Its compact dimension code of A5 28.4×10.7mm and standard contact piece code of C 6.3X0.8X9.5mm make it suitable for a wide range of applications. Available in black housing with a green rocker, it operates within a temperature range of 0~55℃, 0~85℃, or 0~105℃. Choose our factory-direct KCD1 Rocker Switch for superior performance and value.
item
value
Place of Origin
Shanghai, China
Brand Name
SK(shangkai) Yongxing
Model Number
KCD1-11-CA6C-B-G-03
Current Rating
16A
Voltage Rating
250V AC
Mechanical Life
50,000 Cycles
Contact Resistance
≤50mΩ
Insulation Resistance
≥1000MΩ
Dielectric Strength
1500VAC 1 Minute
Electronic Life (cycles)
10,000
Certificate
CQC CE CB ENEC17 ROHS
Circuit
SPST
Dimension Code
A5 28.4×10.7mm
Contact Piece Code
C 6.3X0.8X9.5mm standard
Lamp voltage
no light

Electronic component device for cross-border e-commerceElectronic gadget product for cross-border e-commerce


Key Features

The KCD1 Rocker Switch stands out with its high current rating of 16A and voltage rating of 250VAC, making it suitable for heavy-duty appliances. Its SPST, 2-pin configuration offers simple on-off control, while the absence of a light indicator ensures a clean, minimalist design.

Why Choose Us?

As a factory direct supplier, we offer competitive wholesale pricing without compromising on quality. Our KCD1 Rocker Switch meets multiple international standards, including CE, UL, and ROHS, ensuring safety and compliance. With a long mechanical and electronic life, it provides reliable performance over time.

Applications

This rocker switch is ideal for use in a variety of appliances and electronic devices, where reliable on-off control is essential. Its compact size and durable construction make it suitable for both residential and industrial applications.

Push Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch Customized

Additional information

Max. Current

16A
Max. Voltage

250V AC
Place of Origin

Shanghai, China
Brand Name

Sk(shangkai) yongxing
Model Number

KCD1-11-CA6C-B-G-03/UL
Whether the smart

NO
Mechanical Life

50000 Cycles
Contact Resistance

≤50mΩ
Insulation Resistance

≥1000MΩ
Dielectric Strength

1500VAC 1 Minute
Electronic Life (cycles)

10,000
Circuit

SPST 2pin no light rocker switch
Dimension Code

A6 28.4X10.7mm
Contact Piece Code

C 6.3X0.8X9.5mm
Electrical Life

10,000 cycles
Color

black housing, green rocker
Operating temperature

0~55℃ , 0~85℃ , 0~105℃,
