Description
| Name | KCD1 Rocker Switch |
| Contact Resistance | ≤50mΩ |
| Insulation Resistance | ≥1000MΩ |
| Dielectric Strength | 1500V AC, 1min |
| Operating Temperature | T55,T85,T125 |
| Electronic Life(cycles) | 10000 |
| Max.Rating Current&Voltage | |
 |
16(4)A 250V AC T85 |
 |
16R(4)A 125V AC 16R(4) 250V AC 1HP 125VAC |
 |
14(4)A 250V AC T125, 10(4)A 250V AC T125 16(4)A 250V AC T85, 16A 250V AC |
Why Choose Our KCD1 Rocker Switch?
Our KCD1 Rocker Switch stands out with its waterproof rubber cover, ensuring durability in moist environments. With a maximum rating of 16A 250VAC, it meets diverse electrical demands efficiently. As a factory supplier, we offer competitive wholesale pricing and customization to suit your needs.
What Are the Key Features?
Key features include a contact resistance of ≤50mΩ, insulation resistance of ≥1000MΩ, and dielectric strength of 1500V AC for 1 minute. It operates in temperatures ranging from T55 to T125, with an electrical life of 10,000 cycles and a mechanical life of 100,000 cycles, ensuring longevity and reliability.
How Does It Benefit You?
Choosing our switch means benefiting from factory-direct pricing, quality certifications (CQC, CE, ENEC, UL), and a product designed for superior performance and safety. Its waterproof design and customizable options make it ideal for various electronics and industrial applications.
