Description
|
contact resistance
|
≤50MΩ
|
operating temperature
|
T55 T105
|
|
insulation resistance
|
≥1000MΩ
|
electronic life（cycles）
|
10000
|
|
dielectric strength
|
1500V AC 1min
|
max.rating current & voltage
|
10(3)A 250V AC
|
Why Choose Our KCD3 Rocker Switch?
Our KCD3 Rocker Switch stands out for its exceptional durability and reliability. With a 10A current rating and 250VAC voltage capacity, it's perfect for demanding applications in cars, industrial machinery, and marine vessels. The robust plastic construction ensures longevity, while the sleek white design adds a touch of elegance.
What Makes Our Switch Superior?
As a factory supplier, we offer wholesale pricing without compromising on quality. Our switch boasts a mechanical life of 10,000 cycles and an electric life of the same, ensuring consistent performance over time. Plus, it meets CQC and CE certifications, guaranteeing safety and compliance with industry standards.
Where Can You Use Our Rocker Switch?
Our KCD3 Rocker Switch is versatile and can be used in a variety of settings, including automotive interiors, industrial control panels, marine equipment, and more. Its reliable performance and durable construction make it an ideal choice for any application requiring a high-quality switch.
