Description
| Contact Resistance | ≤50mΩ Automotive Rocker Switch |
| Insulation Resistance | ≥1,000MΩ Mini Rocker Switch |
| Dielectric Resistance | 1,500V AC , 1 min |
| Electronic life(cycles) | 10,000 cycles , 2 Pin Monmentary |
| Mechanical life(cycles) | 50,000 – 100,000 cycles |
| Certification |
CQC , CE , ENEC |
| Max. Rating Current & Voltage (CQC , CE) |
10(3)A 250V AC T85 6(3)A 250V AC T85 |
| Max. Rating Current & Voltage (UL) |
15R(3)A 125V AC , 10R(3)A 250V AC 1/3HP 125V AC |
| Max. Rating Current & Voltage (CB , ENEC) |
10(3)A 250V AC T105,6(3)A 250V AC T105 6A 250V AC ,4A 250V AC T105 |
Why Choose Our KCD3 Mini Momentary Rocker Switch?
Our KCD3 Mini Momentary Rocker Switch is engineered for excellence, offering a robust mechanical life of 100,000 cycles and an electronic life of 10,000 cycles, ensuring long-lasting performance. Its black housing not only adds a sleek look but also enhances durability. Ideal for automotive and industrial control circuits, this switch provides reliable momentary on/off functionality.
What Makes Our Switch Stand Out?
With certifications from CQC, CE, ENEC, and CB, our switch meets the highest safety and quality standards. Its IP40 rating protects against dust ingress, while its wide operating temperature range (T55 and T105) makes it suitable for various environments. As a factory supplier, we offer competitive wholesale prices, making it an excellent choice for bulk purchases.
How Can Our Switch Benefit Your Business?
By choosing our KCD3 Mini Momentary Rocker Switch, you're investing in a product that combines quality, reliability, and affordability. Our switch's high current and voltage ratings (6A 250V AC) make it versatile for a range of applications. Plus, with our comprehensive after-sales service, you can rest assured that any issues will be promptly addressed, ensuring your satisfaction and repeat business.
