Description
|
Certification
|
CQC,CE
|
|
Whether the smart
|
NO
|
|
Place of Origin
|
China
|
|
Brand Name
|
SK(shangkai)
|
|
Model Number
|
Kcd7-11-cf1b-p-p-01 rocker switch
|
|
Max. Current
|
6A
|
|
Max. Voltage
|
250V AC
|
|
Mechanical Life
|
50000 Cycles
|
|
Products name
|
Single Pole Single Throw SPST Rocker Switch Waterproof On off Light
|
|
color
|
red green yellow blue orange black
|
|
Electronic Life
|
10000
|
|
Mechanical Life
|
50000
|
|
Operation temperature
|
T55 Flush Type Switch
|
|
Contact resistance
|
≤50mΩ
|
|
Insulation resistance
|
≥100MΩ
|
|
Dielectric strength
|
1500V
|
|
Material
|
Plastic
|
Why Choose Our KCD7 SPST Waterproof Rocker Switch?
Our KCD7 SPST Waterproof Rocker Switch stands out for its durability, reliability, and versatility. Designed specifically for medical and industrial applications, it can withstand harsh environments and ensure consistent performance. The waterproof feature makes it ideal for outdoor or humid settings, where other switches might fail. As a factory supplier, we offer competitive wholesale pricing, making it an affordable choice for bulk purchases.
What Are the Key Specifications of Our Switch?
Our switch boasts a maximum current of 6A and a maximum voltage of 250V AC, making it suitable for a wide range of applications. It has a mechanical life of 50,000 cycles and an electronic life of 10,000 cycles, ensuring long-lasting reliability. The contact resistance is ≤50mΩ, and the insulation resistance is ≥100MΩ, providing excellent safety and performance. Additionally, it comes with CQC, CE, and RoHS certifications, meeting international standards.
What Are the Advantages of Buying from Us?
As a direct factory supplier, we offer several advantages. Firstly, we can provide competitive pricing due to our direct manufacturing capabilities. Secondly, we have strict quality control measures in place to ensure that every switch meets our high standards. Lastly, our excellent customer service team is always ready to assist you with any questions or concerns you may have, making your purchasing experience smooth and hassle-free.
