Description
With a maximum current rating of 6A and a voltage rating of 250V AC, this rocker switch is built to last. It features a contact resistance of 50mΩ Max and an insulation resistance of 1000MΩ Min, ensuring reliable performance. The switch has an electrical life of 10,000 cycles and a mechanical life of 50,000-100,000 cycles, making it a durable choice for your needs.
Available in a sleek black housing, this rocker switch is not only functional but also aesthetically pleasing. It comes with options for amber, orange-red, blue, or green LED colors, allowing you to customize the look to suit your application.
Our KCD8 3-Pin Rocker Switch is certified with UL, CE, CQC, CB, ENEC, and ROHS, ensuring it meets the highest quality and safety standards. With an IP41 rating, it offers protection against dust and water ingress.
Choose our factory-direct KCD8 3-Pin Black Rocker Switch for wholesale pricing, reliable performance, and exceptional durability. We are your trusted supplier for all your rocker switch needs.
| Contact Resistance | ≤50mΩ rocker switches for electric fireplace |
| Insulation Resistance | ≥1,000MΩ |
| Dielectric Resistance | 1,500V AC , 1 min |
| Electronic life(cycles) | 10,000 cycles 4 pin on-off rocker switch |
| Operating Temperature | T55 rocker switch |
| Certification |
CQC , CE |
| Max. Rating Current & Voltage (CQC , CE) |
6A 250V AC |
Product Features
Our KCD8 3-Pin Black Rocker Switch stands out with its durable construction, reliable performance, and customizable LED options. It's perfect for a wide range of industrial and commercial applications.
Why Choose Us?
As a factory-direct supplier, we offer wholesale pricing on our high-quality rocker switches. You can trust in our product's durability and performance, backed by multiple certifications.
Applications
This rocker switch is ideal for use in electric fireplaces, control panels, and various industrial equipment. Its customizable LED colors make it suitable for applications where visual indication is required.
