Description
Yongxing KCD8 3-Pin On-Off Rocker Switch
Introducing our premium KCD8 3-pin on-off rocker switch, a high-quality product designed for durability and reliability. As a factory direct supplier, we offer wholesale prices on this essential component, perfect for generators, electric fireplaces, and various other applications.
Product Specifications
- Contact Resistance: ≤50mΩ
- Insulation Resistance: ≥1,000MΩ
- Dielectric Resistance: 1,500V AC, 1 min
- Electronic Life: 10,000 cycles
- Operating Temperature: Suitable for a wide range of temperatures
- Certification: CQC, CE
- Max. Rating Current & Voltage: 6A 250V AC
- Mechanical Life: 50,000-100,000 cycles
- IP Level: IP41
- Housing Color: Black
- LED Color Options: Amber, Orange, Red, Blue, Green
- Pins: 2-pin/3-pin available
Product Advantages
Our KCD8 rocker switch stands out with its long mechanical life, high insulation resistance, and compatibility with a wide range of voltages and currents. The durable housing and multiple LED color options make it a versatile choice for various applications. As a supplier, we ensure competitive pricing and fast delivery times.
After-Sales Service
We offer comprehensive after-sales service, including technical support and warranty coverage. Our team is dedicated to ensuring your satisfaction with our products.
| Contact Resistance | ≤50mΩ rocker switches for electric fireplace |
| Insulation Resistance | ≥1,000MΩ |
| Dielectric Resistance | 1,500V AC , 1 min |
| Electronic life(cycles) | 10,000 cycles 4 pin on-off rocker switch |
| Operating Temperature | T55 rocker switch |
| Certification |
CQC , CE |
| Max. Rating Current & Voltage (CQC , CE) |
6A 250V AC |
Why Choose Our KCD8 3-Pin Rocker Switch?
Our KCD8 3-pin rocker switch is designed for durability and reliability, making it an ideal choice for generators, electric fireplaces, and more. With a long mechanical life and high insulation resistance, it ensures stable performance in various conditions.
What Are the Key Features?
Key features include a 3-pin design, compatibility with 6A 250V AC, and an IP41 rating for protection against dust and water. The switch also offers multiple LED color options for customization.
How Can We Benefit You?
As a factory direct supplier, we offer wholesale prices and fast delivery times. Our comprehensive after-sales service ensures your satisfaction with our products, making us a trusted partner for your switch needs.
