Description
Specifications:
– Max. Current: 6A
– Max. Voltage: 250V AC
– Place of Origin: Shanghai, China
– Brand Name: SK (Shangkai)
– Model Number: KCD8
– Mechanical Life: 50,000-100,000 cycles
– IP Level: IP40, IP65
– Housing Color: Black
– LED Color Options: Amber, Orange, Red, Blue, Green
– Contact Resistance: ≤50mΩ
– Insulation Resistance: ≥1000MΩ
– Pins: 2-pin/3-pin
– Electrical Life: 10,000 Times
– Certifications: UL, CE, CQC, CB, ENEC, ROHS
Advantages:
Our rocker switch stands out with its long mechanical life, ensuring durability and reliability. The wide range of LED color options allows for customization to match any application’s aesthetic. With IP40 and IP65 ratings, it offers protection against dust and water, making it suitable for various environments.
Applications:
Ideal for generators, electric fireplaces, industrial machinery, and more. Its 3-pin design provides stable on-off functionality, essential for reliable control in electrical systems.
After-Sales Service:
We provide comprehensive after-sales support, including technical assistance and warranty services. As a factory supplier, we ensure prompt delivery and competitive pricing, making us the preferred choice for bulk purchases.
| Contact Resistance | ≤50mΩ rocker switches for electric fireplace |
| Insulation Resistance | ≥1,000MΩ |
| Dielectric Resistance | 1,500V AC , 1 min |
| Electronic life(cycles) | 10,000 cycles 4 pin on-off rocker switch |
| Operating Temperature | T55 rocker switch |
| Certification |
CQC , CE |
| Max. Rating Current & Voltage (CQC , CE) |
6A 250V AC |
Why Choose Our KCD8 3-Pin Rocker Switch?
Our KCD8 3-Pin Rocker Switch offers unmatched durability with a mechanical life of 50,000-100,000 cycles, ensuring reliable performance in demanding applications. The switch's IP40 and IP65 ratings provide protection against dust and water, making it suitable for various environments, from industrial settings to outdoor equipment.
Customizable LED Colors for Versatility
With a range of LED color options including Amber, Orange, Red, Blue, and Green, our rocker switch can be customized to match the aesthetic of any device or application. This feature not only enhances functionality but also adds a touch of style to your products.
Factory Direct Pricing and Support
As a factory supplier, we offer wholesale pricing on our KCD8 3-Pin Rocker Switch, making it an affordable choice for bulk purchases. Our comprehensive after-sales support includes technical assistance and warranty services, ensuring peace of mind for our customers. Choose us for reliable, high-quality electrical components at competitive prices.
