Description
KCD8 3-Pin Waterproof Rocker Switch – Wholesale from Factory Supplier
Our KCD8 3-pin waterproof rocker switch is a high-quality, reliable electrical component suitable for a wide range of applications. As a factory supplier, we offer wholesale pricing and ensure that each switch meets strict quality standards.
Product Specifications:
- Max. Current: 6A
- Max. Voltage: 250V AC
- Place of Origin: Shanghai, China
- Brand Name: SK(Shangkai)
- Model Number: KCD8
- IP Level: IP40, IP65
- Housing Color: Black
- LED Color: Amber, Orange, Red, Blue, Green
- Contact Resistance: ≤50mΩ
- Insulation Resistance: ≥1000MΩ
- Electrical Life: 10,000 Cycles
- Mechanical Life: 50,000-100,000 Cycles
- Certifications: UL, CE, CQC, CB, ENEC, ROHS
Product Advantages:
Our KCD8 rocker switch stands out with its waterproof design (IP65 rating), ensuring durability and reliability even in harsh environments. The switch is easy to install and operate, making it ideal for various applications. With a mechanical life of 50,000-100,000 cycles, it offers long-lasting performance. Additionally, our factory-direct pricing and wholesale options make it a cost-effective choice for bulk purchases.
After-Sales Service:
We provide comprehensive after-sales service, including technical support and warranty coverage. Our dedicated customer service team is always ready to assist you with any questions or concerns.
| Contact Resistance | ≤50mΩ rocker switches for electric fireplace |
| Insulation Resistance | ≥1,000MΩ |
| Dielectric Resistance | 1,500V AC , 1 min |
| Electronic life(cycles) | 10,000 cycles 4 pin on-off rocker switch |
| Operating Temperature | T55 rocker switch |
| Certification |
CQC , CE |
| Max. Rating Current & Voltage (CQC , CE) |
6A 250V AC |
Why Choose Our KCD8 Waterproof Rocker Switch?
Our KCD8 waterproof rocker switch is designed to withstand harsh environments with its IP65 rating, ensuring reliable performance even in wet or dusty conditions. The switch is easy to install and operate, making it suitable for a wide range of applications.
What Are the Key Features of Our Switch?
Key features include a 3-pin design, 6A 250V AC rating, and a mechanical life of 50,000-100,000 cycles. The switch also comes with multiple LED color options and is certified by UL, CE, CQC, CB, ENEC, and ROHS.
How Can Our Switch Benefit Your Business?
As a factory supplier, we offer wholesale pricing, making our KCD8 switch a cost-effective choice for bulk purchases. The switch's high reliability and long life can reduce maintenance costs and downtime, ultimately benefiting your business operations.
