Description
Our terminal blocks are crafted with precision using premium materials: brass contacts with tin plating for optimal conductivity and durability, and a PA66, UL94V-0 housing for superior flame resistance and environmental stability. Operating temperatures range from -40°C to 150°C, with a short-time temperature tolerance of +250°C for 5 seconds, making them suitable for a wide range of applications.
Electrically, these terminal blocks excel with a rated voltage of 250V~450V, a rated current of 16A, and a low contact resistance of 20mΩ, ensuring efficient and reliable connections. They also boast high insulation resistance (>5000MΩ DC500V) and withstand voltage of AC2000V/1Min, providing enhanced safety and performance.
With a pitch of 7.62mm and 2-3 poles, our terminal blocks are versatile and easy to install. They are CQC, CE, and ROHS certified, guaranteeing compliance with international standards. Whether you’re in the automotive, electronics, or industrial sector, our Krone IDC Terminal Blocks are the ideal choice for your connectivity needs.
As a factory-direct supplier, we offer competitive pricing and excellent customer service, including after-sales support. Choose us for your wholesale needs and experience the difference in quality and service.
| Material | |
| Contact | Brass, Tin Plated |
| Housing | PA66 ,UL94V-0 |
| Color | Green pa66 terminal connector |
| Environmental | |
| Operating temperature | -40°C ~ 150°C |
| Short-time temperature | +250°C for 5 sec |
| Electrical | |
| Rated voltage | 300V connector blocks |
| Rated current | 16A 2 pins connector |
| Contact resistance | 20mΩ |
| Insulation resistance | >5000MΩ DC500V |
| Withstanding voltage | AC2000V/1Min |
Why Choose Our Krone IDC Terminal Blocks?
Our Krone IDC Terminal Blocks stand out due to their premium materials, including brass contacts with tin plating and a PA66, UL94V-0 housing, ensuring durability and safety. With a wide operating temperature range and excellent electrical properties, they are perfect for demanding applications.
What Are the Key Features?
Key features include a rated voltage of 250V~450V, a rated current of 16A, and low contact resistance. They also offer high insulation resistance and withstand voltage, providing reliable and safe connections. Available in multiple colors and with 2-3 poles, they are versatile and easy to install.
Why Buy From Us?
As a factory-direct supplier, we offer competitive pricing and excellent customer service. Our terminal blocks are CQC, CE, and ROHS certified, ensuring compliance with international standards. Choose us for your wholesale needs and experience quality and service that exceeds expectations.
