Wholesale Medical 3 Pin Rocker Switch Supplier

Category: Tags: , ,
100 - 2,999  pieces
$0.31

3,000 - 4,999  pieces
$0.29

>= 5,000  pieces
$0.27
0 reviews

Wholesale 3 Pin Rocker Switch Supplier for Medical Equipment

Description

Introducing our premium 3 Pin Rocker Switch with Green Light Illumination, specifically designed for medical equipment. As a factory-direct supplier, we offer competitive wholesale prices. This switch features a robust 16A current rating and 250V AC voltage rating, ensuring reliable performance. With a mechanical life of 50,000 cycles and an electronic life of 10,000 cycles, it outlasts many competitors. The switch is CQC, CE, CB, ENEC17, and ROHS certified, guaranteeing safety and quality. Its SPST illuminated circuit and compact A5 28x11mm dimension make it ideal for space-constrained applications. The black housing with a green rocker not only looks sleek but also provides easy visibility. Choose us for your wholesale needs and experience unmatched quality and service.
item
value
Place of Origin
Shanghai, China
Brand Name
SK(shangkai) Yongxing
Model Number
KCD1-11N-CA5C-W-G-01-AC110
Current Rating
16A
Voltage Rating
250V AC
Mechanical Life
50,000 Cycles
Contact Resistance
≤50mΩ
Insulation Resistance
≥1000MΩ
Dielectric Strength
1500VAC 1 Minute
Electronic Life (cycles)
10,000
Certificate
CQC CE CB ENEC17 ROHS
Circuit
SPST illuminated
Dimension Code
A5 28x11mm
Contact Piece Code
C 6.3X0.8X10mm standard
Lamp voltage
AC110V

Electronic component device for cross-border e-commerceElectronic gadget product for cross-border e-commerce


Why Choose Our 3 Pin Rocker Switch?

Our 3 Pin Rocker Switch is designed with medical equipment in mind, offering reliable performance and longevity. With a 16A current rating and 250V AC voltage, it can handle demanding applications. The illuminated green light provides clear visibility, making it easy to operate in low-light conditions.

What Makes Us Different?

As a factory-direct supplier, we offer competitive wholesale prices without compromising on quality. Our switch is CQC, CE, CB, ENEC17, and ROHS certified, ensuring it meets the highest safety standards. With a mechanical life of 50,000 cycles, it outlasts many other switches on the market, providing excellent value for money.

Where Can You Use Our Switch?

Our 3 Pin Rocker Switch is perfect for medical equipment, control panels, and industrial machinery. Its compact size and illuminated design make it ideal for applications where space is limited and visibility is crucial. Choose us for your wholesale needs and experience the difference in quality and service.

Push Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch Customized

Additional information

Max. Current

16A
Max. Voltage

250V AC
Place of Origin

Shanghai, China
Brand Name

Sk(shangkai) yongxing
Model Number

KCD1-11N-CA5C-W-G-01-AC110(225)
Whether the smart

NO
Mechanical Life

50000 Cycles
Contact Resistance

≤50mΩ
Insulation Resistance

≥1000MΩ
Dielectric Strength

1500VAC 1 Minute
Electronic Life (cycles)

10,000
Circuit

SPST Illuminated rocker switch
Dimension Code

A5 28X11mm
Contact Piece Code

C 6.3X0.8X9.5mm
Electrical Life

10,000 cycles
Color

black housing, green rocker
Lamp

AC2110V green light
