Description
|
item
|
value
|
|
Place of Origin
|
Shanghai, China
|
|
Brand Name
|
SK(shangkai) Yongxing
|
|
Model Number
|
KCD3-11-CA1H-W-W-01
|
|
Max. Current
|
6(3)A
|
|
Max. Voltage
|
250V AC
|
|
Mechanical Life
|
50000 Cycles
|
|
Contact Resistance
|
≤50mΩ
|
|
Insulation Resistance
|
≥1000MΩ
|
|
Dielectric Strength
|
1500VAC 1 Minute
|
|
Electronic Life (cycles)
|
10,000
|
|
Certificate
|
CB ENEC17 ROHS
|
|
Circuit
|
SPST mini rocker switch t85
|
|
Dimension Code
|
A1 (21.7x15x15.8 , 19.1x13x13)
|
|
Contact Piece Code
|
H (7.5 length, 2.2×0.6 welding type)
|
|
Color
|
Red,Yellow,Green,Black,Blue,Orange,White,Gray
|
|
Function
|
On Off rocker switch panel mount
|
Why Choose Our KCD3-11 Mini Rocker Switch?
Our KCD3-11 Mini Rocker Switch stands out due to its high-quality construction, CQC and CE certifications, and long mechanical and electronic life. With a max current of 6A and max voltage of 250V AC, it's suitable for a wide range of applications, from household appliances to industrial equipment. The variety of colors available ensures you can find the perfect match for your project.
What Makes Our Switch Different?
As a factory supplier, we offer wholesale pricing without compromising on quality. Our switch has a contact resistance of ≤50mΩ and insulation resistance of ≥1000MΩ, ensuring optimal electrical performance. The dielectric strength of 1500VAC for 1 minute provides an extra layer of safety. Additionally, our switch is easy to install and use, making it a preferred choice for both professionals and DIY enthusiasts.
Who Can Benefit from Our Switch?
Our KCD3-11 Mini Rocker Switch is ideal for wholesalers, retailers, and anyone in need of a reliable and high-quality switch. Whether you're working on a home automation project, an industrial equipment upgrade, or simply replacing a faulty switch, our product is the perfect choice. With our factory-direct pricing and exceptional service, you can't go wrong with our KCD3-11 Mini Rocker Switch.
