Description
Key Features:
- Material Excellence: Crafted with brass contacts (tin-plated) and a PA66, UL94V-0 housing, ensuring durability and safety.
- Electrical Performance: Rated at 300V and 16A, with a contact resistance of 20mΩ and insulation resistance exceeding 5000MΩ at DC500V.
- Environmental Resilience: Operates efficiently from -40°C to 150°C, withstanding short-term temperatures up to +250°C for 5 seconds.
- Versatile Application: Ideal for wire connecting and spring terminal blocks, accommodating conductor sizes from 21 to 30 AWG.
- Certified Quality: CQC certified, ensuring compliance with industry standards.
Our connectors stand out with their robust construction, excellent electrical properties, and wide temperature range, making them a reliable choice for demanding environments. As a trusted supplier, we provide competitive pricing, bulk order discounts, and excellent customer service. Order now and experience the difference!
| Material | |
| Contact | Brass, Tin Plated |
| Housing | PA66 ,UL94V-0 |
| Color | Green terminal connectors |
| Environmental | |
| Operating temperature | -40°C ~ 150°C |
| Short-time temperature | +250°C for 5 sec |
| Electrical | |
| Rated voltage | 300V |
| Rated current | 16A electrical busbar connectors |
| Contact resistance | 20mΩ |
| Insulation resistance | >5000MΩ DC500V |
| Withstanding voltage | AC2000V/1Min male female plastic connectors |
Why Choose Our Plastic Electrical Bus Connectors?
Our connectors are designed to withstand harsh industrial and automotive environments, offering exceptional electrical performance and durability. With a wide temperature range and high insulation resistance, they ensure reliable connections even in demanding conditions.
What Makes Our Connectors Stand Out?
Our connectors are crafted with premium materials, including brass contacts and a PA66, UL94V-0 housing, ensuring longevity and safety. Additionally, they are CQC certified, meeting stringent industry standards.
How Can We Help You?
As a factory supplier, we offer competitive pricing on bulk orders, along with excellent customer service. Whether you need a small quantity or a large shipment, we are here to meet your needs. Contact us today to discuss your requirements and place an order.
